Hp 1tb 6g Sata 7.2k Rpm Sff (2.5-inch) Sc Midline 1yr Warranty Hard Drive 655710-b21
1TB 6G SFF (2.5-inch) SC Midline
Description
HP SATA hard drives are designed for reliability and mass storage demanded by
today's server and storage environments. The SATA hard drive portfolio is
categorized into two categories: Entry (ETY) and Midline (MDL) hard drives. HP
SATA Entry hard drives are the lowest unit-cost solution for entry level
servers. Designed for economical reliability and performance for non-mission
critical applications, Entry and Midline SATA hard drives provide the best price
advantage for these lower workload environments. These hard drives are available
in Small Form Factor (2.5in) and Large Form Factor (3.5in) for both hot plug and
non-hot plug environments.
Designed and Engineered to Provide Reliable and Cost Efficient Data Storage.
Increased Midline drive reliability of approximately two times that of Entry
drives based on a <40% workload. Lowers cost without sacrificing reliability
with Enterprise class hard drives at the lowest $/GB. Cost optimized and
capacity optimized solutions that provide up to 3TB storage in a single device.
Available in 2.5in (SFF) and 3.5in (LFF) form factors in a wide variety of
capacity points. Rotational Vibration Sensors: Enhanced rotational vibration
tolerance provides Enterprise class reliability in a Midline drive. 3Gb/sec data
transfer rate supporting existing servers. New 6Gb/sec data transfer rate
exclusively for HP ProLiant Gen8 servers, with new hot plug carrier design.
Midline SATA offers customers the lowest $/GB drives and increased features over
Entry SATA.
Increased reliability of approximately two times Entry drive reliability based
on <40% workload. Detects a specific temperature threshold, drive throttles
performance to protect itself. Improved rotational vibration robustness for
immunity to environmental rotational affects. Native Command Queuing (NCQ),
Buffer Error Detection, Time Limited Error Recovery (TLER), Microcode Download
and 3Gb/s compatibilty. Ship with a standard one year warranty.
SATA Applications.
With the attractive low acquisition cost and high capacity points of SATA drives
it is important to understand the appropriate applications where SATA drives
should be used. Proper usage (IE <40% workload) of these drives will lessen the
probability of drive failure. For high IOP's performance intense applications,
mission critical applications or extreme environments HP recommends Enterprise
Serial Attached SCSI (SAS) hard drives.
Product dimensions (W x D x H) 2.98 x 4.67 x 0.62 in
Weight ( Imperial ) 1.36 kg
Weight ( Metric ) 3.0 lb
Extended specifications
Technical Information
Storage Capacity 1 TB
Drive Performance
Maximum External Data Transfer Rate 768 MBps (6 Gbps)
Rotational Speed 7200 rpm
Interfaces/Ports
Drive Interface SATA
Drive Interface Standard SATA/600
SATA Pin 7-pin
Physical Characteristics
Drive Type Internal
Drive Width 2.5"
Height 1.0"
Width 4.4"
Depth 7.3"
Weight (Approximate) 3.00 lb
Miscellaneous
Green Compliant Yes
Green Compliance Certificate/Authority REACH
Warranty
Limited Warranty 1 Year
Marketing Text | HP SATA drives are designed for the reliability and larger capacities demanded by today's entry server and external storage environments. |
PI Date | Apr 2012 |
Brand Name | HP |
Manufacturer Web Site | http://www.hp.com/ |
Form Factor | SFF |
Product Type | Hard Drive |
Interface | SATA |
Rotational Speed | 7200rpm |
Size | 2.5inch |
Storage Capacity | 1TB |
External Data Transfer Rate | 6GBits/s |
Depth (mm) | 110.7 |
Height (mm) | 184.2 |
Width (mm) | 26.4 |
Weight (Kg) | 1.4 |
Operating Temperature | 10 to 35°C |
Other Features | * Seek Time: Single Track : 0.7 ms, Full-Stroke: 16.96 ms * Bytes/Sector : 512 * Compat : HP ProLiant BL460c Gen8 Server series, HP ProLiant DL360p Gen8 Server series, HP ProLiant DL380p Gen8 Server series, HP ProLiant SL250s Gen8 Server series |
Warranty Information | 3 Years Limited Warranty |
