ASRock H510M-HDV Motherboard H510 Micro-ATX: Socket 1200 For Intel 11th/10th Gen. Processors 2 x DDR4 DIMM Slots,

SKU
367959
Brand
MPN
H510M-HDV
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $93.00 Regular Price $108.00
Buy Now And Earn 93 Reward Points!

QUICK OVERVIEW

4 x SATA3 6.0, HDMI/DVI-D/D-Sub, USB 3.2/USB2.0, Gigabit LAN, 7.1 Audio, 19.7x18.8 cm

Unique Feature



ASRock Super Alloy

- Premium 50A Power Choke

- Sapphire Black PCB

- High Density Glass Fabric PCB

ASRock Full Spike Protection (for all USB, Audio, LAN Ports)

ASRock Live Update & APP Shop



CPU



- Supports 10th Gen Intel Core Processors and 11th Gen Intel Core Processors (LGA1200)

- 5 Power Phase design

- Supports Intel Turbo Boost Max 3.0 Technology



Chipset



- Intel H510



Memory



- Dual Channel DDR4 Memory Technology

- 2 x DDR4 DIMM Slots

- Supports DDR4 3200 / 2933 / 2800 / 2666 / 2400 / 2133 non-ECC, un-buffered memory*

- Supports ECC UDIMM memory modules (operate in non-ECC mode)

- Max. capacity of system memory: 64GB**

- Supports Intel Extreme Memory Profile (XMP) 2.0



*11th Gen Intel Core (i9/i7/i5) support DDR4 up to 3200; Core (i3), Pentium and Celeron support DDR4 up to 2666 natively.

10th Gen Intel Core (i9/i7) support DDR4 up to 2933; Core (i5/i3), Pentium and Celeron support DDR4 up to 2666 natively.



**Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows 32-bit OS. For Windows 64-bit OS with 64-bit CPU, there is no such limitation.



BIOS



- 128Mb AMI UEFI Legal BIOS with multilingual GUI support

- ACPI 6.0 Compliant wake up events

- SMBIOS 2.7 Support

- CPU Core/Cache, CPU GT, VCCSA, DRAM, VCCIO, CPU Standby, VCCIN AUX Voltage Multi-adjustment



Graphics



- 11th Gen Intel Core Processors support Intel Xe Graphics Architecture (Gen 12). 10th Gen Intel Core Processors support Gen 9 Graphics

- Three graphics output options: D-Sub, DVI-D and HDMI**

- Supports HDMI 2.0 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz

- Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI 2.0 Port (Compliant HDMI monitor is required)

- Supports HDCP 2.3 with DVI-D and HDMI 2.0 Ports



*Intel UHD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.

11th Gen Intel Core Processors support HDMI 2.0. 10th Gen Intel Core Processors support HDMI 1.4.



**Supports up to 2 displays simultaneously



Audio



- 7.1 CH HD Audio (Realtek ALC897 Audio Codec)

- Supports Surge Protection



LAN



- PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- 1 x Realtek RTL8111H

- Supports Wake-On-LAN

- Supports Lightning/ESD Protection

- Supports Energy Efficient Ethernet 802.3az

- Supports PXE



Slots



11th Gen Intel Core Processors

- 1 x PCI Express 4.0 x16 Slot*

10th Gen Intel Core Processors

- 1 x PCI Express 3.0 x16 Slot*



- 1 x PCI Express 3.0 x1 Slot



*Supports NVMe SSD as boot disks



Storage



- 4 x SATA3 6.0 Gb/s Connectors, support Intel Rapid Storage Technology 18, NCQ, AHCI and Hot Plug

Connector



- 1 x SPI TPM Header

- 1 x Chassis Intrusion and Speaker Header

- 1 x CPU Fan Connector (4-pin)*

- 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**

- 1 x 24 pin ATX Power Connector

- 1 x 8 pin 12V Power Connector

- 1 x Front Panel Audio Connector

- 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)

- 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)



*The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power.



**The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power.

CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.



Rear Panel I/O



- 1 x PS/2 Keyboard Port

- 1 x PS/2 Mouse Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 2 x USB 3.2 Gen1 Ports (Supports ESD Protection)

- 4 x USB 2.0 Ports (Supports ESD Protection)

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)

- HD Audio Jacks: Line in / Front Speaker / Microphone



Software and UEFI



Software

- ASRock Motherboard Utility (A-Tuning)

- ASRock XFast LAN

UEFI

- ASRock EZ Mode

- ASRock Full HD UEFI

- ASRock My Favorites in UEFI

- ASRock Instant Flash

- ASRock Internet Flash



*These utilities can be downloaded from ASRock Live Update & APP Shop.



Support CD



- Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar



Accessories



- Quick Installation Guide, Support CD, I/O Shield

- 2 x SATA Data Cables



Hardware Monitor



- Fan Tachometer: CPU, Chassis/Water Pump Fans

- Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans

- Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans

- CASE OPEN detection

- Voltage monitoring: CPU Vcore, +12V, +5V, +3.3V



Form Factor



- Micro ATX Form Factor: 7.76-in x 7.4-in, 19.7 cm x 18.8 cm

- Solid Capacitor design



OS



- Microsoft Windows 10 64-bit



Certifications



- FCC, CE

- ErP/EuP ready (ErP/EuP ready power supply is required)







All specifications are subject to change without notice.

Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details.
