MSI A320M-A Pro Max Motherboard

SKU
290424
Brand
MPN
A320M-A PRO MAX
Warranty
1 Year Manufacturer's return to base
Availability
Preorder 3-4 weeks
Freight Estimate
$97.00
Buy Now And Earn 97 Reward Points!
Audio
Audio Channels: 7.1
Basic
Product Type: Desktop Motherboard
Maximum Memory: 32 GB
Form Factor: Micro ATX
Processor Supported: Ryzen
Athlon
Athlon X4
A-Series
Total Processor Supported: 1
Controller Type: Serial ATA/600
Processor Socket: Socket AM4
Brand Name: MSI
Memory Technology: DDR4 SDRAM
Chipset Manufacturer: AMD
Number of Memory Slots: 2
Gigabit Ethernet: Yes
Number of SATA Interfaces: 4
Number of PCI Express x1 Slots: 1
Onboard Video: CPU Dependent Video
RAID Supported: Yes
Number of Total Expansion Slots: 2
Number of PCI Express x16 Slots: 1
Total Number of USB Ports: 6
Total Number of Onboard USB Ports: 6
Total Number of PCI Express Slots: 2
Memory Form Factor: DIMM
UDIMM
Number of M.2 Interfaces: 1
Number of USB 3.2 Ports: 4
Number of Onboard USB 3.2 Ports: 2
General Information
Product Type: Desktop Motherboard
Manufacturer Website Address: http://au.msi.com
Manufacturer: MSI
Product Model: A320M-A PRO MAX
Product Name: A320M-A PRO MAX Desktop Motherboard
Product Series: PRO
Brand Name: MSI
I/O Controller
RAID Levels: 1
0
10
Controller Type: Serial ATA/600
RAID Supported: Yes
I/O Expansions
Number of PCI Express x1 Slots: 1
Number of Total Expansion Slots: 2
Number of PCI Express x16 Slots: 1
Total Number of PCI Express Slots: 2
Interfaces/Ports
HDMI: Yes
DVI: Yes
Number of Network (RJ-45) Ports: 1
Total Number of USB Ports: 6
Number of USB 2.0 Ports: 2
Number of USB 3.2 Ports: 4
Memory
Maximum Memory: 32 GB
Memory Technology: DDR4 SDRAM
Number of Memory Slots: 2
Memory Form Factor: UDIMM
DIMM
Memory Speed Supported: 2667 MHz
2667 MHz (O.C.)
1866 MHz
2400 MHz
3066 MHz (O.C.)
3200 MHz (O.C.)
3000 MHz (O.C.)
2133 MHz
2933 MHz (O.C.)
2800 MHz (O.C.)
Miscellaneous
Country of Origin: China
Network & Communication
Gigabit Ethernet: Yes
Onboard Interfaces
Number of SATA Interfaces: 4
Total Number of Onboard USB Ports: 6
Number of Onboard USB 2.0 Ports: 4
Number of M.2 Interfaces: 1
Number of Onboard USB 3.2 Ports: 2
Physical Characteristics
Form Factor: Micro ATX
Width: 236.2 mm
Depth: 200.7 mm
Processor & Chipset
Processor Supported: Ryzen
A-Series
Athlon
Athlon X4
Total Processor Supported: 1
Processor Socket: Socket AM4
Chipset Manufacturer: AMD
Video
Onboard Video: CPU Dependent Video
