AJAX SUPERIOR SEISMOPROTECT G3 FIBRA WHITE 2YR 117737.269.WH1
Superior SeismoProtect G3 Fibra.
It is designed to detect vibrations caused by drilling or cutting attempts and explosions. The detector also identifies physical force, such as bending or pushing, temperature changes near the enclosure, and quickly reacts to shocks and tilt. The advanced software algorithm analyzes all detected vibrations to filter out false alarms. Installation is easy and convenient, requiring no extra cost: everything an installer might need to do the job is included.
Ajax technologies against false alarms
When the device detects vibration, the structure-borne sound is instantly processed by hardware and converted into a signal, which is analyzed and correlated by a software algorithm. This procedure helps promptly distinguish real threats from false alarms caused by a swinging door, repair or maintenance work nearby, and passing trains or large vehicles.
| Sensitive elements | piezoelectric sensor, accelerometer, digital temperature sensor |
| Operating radius - Concrete | 4 meters |
| Operating radius - Steel | 2 meters |
| Tilt sensor activation threshold | from 5° to 25° (adjustable) |
| Sensitivity | 3 levels |
| Option to ignore single shock | Adjusted by a PRO or user with admin rights in Ajax apps. |
| Self-test of sensitive elements | Self-testing can be automatic or manual. |
| Tamper alarm | 2 tampers |
| Alarm in case of high temperature | at temperatures above +70 °C |
| Alarm in case of rapid temperature rise | when the temperature rises more than 5 °C in 5 seconds or less |
| Enclosure drilling detection | to detect the enclosure damage |
| Power supply | Fibra line power supply (5−30 V⎓, up to 26 mW) |
| Line connection | 4-core cable |
| Fibra line length | up to 2,000 meters (When using the U/UTP cat.5 twisted pair.) |
| Detector dimensions | 88 × 88 × 20 mm |
| Detector weight | 170 g |
| Mounting plate weight | 224 g |
| Armored cable weight | 130 g |
| Armored cable length | 1.5 m |
| Operating temperature range | from −25 °C to +70 °C |
| Operating humidity | up to 95% |
| Protection class | IP43, IK04 |
