AJAX HUB BP BLACK 2YR 126868.263.BL3
Hub BP Jeweller
Wireless battery-powered control panel with external antenna connections.
Off-grid security made simple
Hub BP Jeweller is an innovative security control panel designed to secure properties without a constant power supply. It's ideal for protecting vacant houses, construction sites, and temporarily unused offices. Unlike other control panels, Hub BP is powered by internal and external batteries, ensuring long-term autonomous operation. Hub supports event photo verification and features dual SIM connectivity, guaranteeing reliable communication. Thanks to its battery power saver feature, the device optimizes battery usage, providing continuous protection for extended periods.
Impressive autonomy for challenging locations
Hub BP Jeweller operates on internal and external batteries or alternative supplies like solar panels, ensuring exceptional autonomy. This feature makes it ideal for sites where it is impossible to install devices powered by the mains. With its battery power saver feature, the hub can function for months, reducing the need for frequent maintenance visits. This innovation protects remote or off-grid locations, expanding installation possibilities for security professionals.
Advanced battery power saver
Hub BP Jeweller's advanced feature, applicable to both internal and external batteries, significantly extends operational life. Battery power saver minimizes maintenance visits and reduces costs, particularly for remote or hard-to-access facilities, enhancing overall system efficiency and reliability.
Hub BP manages all the Ajax devices in the system to alert users about open doors, broken windows, threats of fire and flooding. If burglars break into your facility, Hub BP will notify the monitoring station and send photos from the MotionCam detectors. You won’t need to live under the constant supervision of the security cameras to know what’s going on.
Alarm photo verification in 9 seconds
Hub BP works with MotionCam and MotionCam Outdoor motion detectors. When detectors are triggered, they take a series of photos. It helps to evaluate the situation at the facility. Visual verification helps you instantly assess the situation, relieving users of unnecessary anxiety, and security companies — from false calls of patrols.
Motion detected
Alarm triggered
Evidence captured
Hub BP can be simultaneously connected to two Internet service providers — via 4G/ LTE2 cellular networks. The automatic switching between channels takes seconds.
9 security groups
50 users
100 devices in the system
2,000 m of radio communication range
The Hub BP radio network covers several floors and separate buildings — thanks to the communication range of 2,000 meters and the ability to connect five range extenders. To manage access and security zoning of the facility, the hub allows connecting 50 users and creating 9 security groups. Hub 2 is a perfect choice for home and business security.
Resistant to sabotage
Whatever happens to Hub BP, the security company and the users will be notified. No one can disconnect the hub unnoticed when the facility is disarmed. If an intruder attempts to dismount the device, this will trigger the tamper immediately. The Ajax Cloud server can notify about the loss of connection with the hub in 60 seconds due to frequent polling. Even if the building is de-energized, the hub will protect the object for up to 16 hours with a built-in backup battery.
Devices polling from 12 s
Detection of hub connection loss in 60 s
| Capacity | Wireless Ajax devices - up to 100. Specifically, up to 10 sirens or keypads with a built-in siren and 5 range extenders. |
| Ajax NVRs | up to 36 |
| Ajax cameras | up to 224 via Ajax NVRs and up to 492 standalone |
| Third-party IP cameras | up to 10 when using RTSP via SDK, up to 224 when using ONVIF via Ajax NVRs |
| Users | up to 50 |
| Automation scenarios | up to 32 |
| Security groups (Areas) | up to 9 |
| Rooms | up to 50 |
| Event log | up to 1,000 events |
| Wireless communication | Proprietary wireless communication technologies to transmit alarms, events and photo verification Key features: Two-way communication. Advanced anti-sabotage. Block encryption featuring a dynamic key. Instant notifications. Remote configuration via the Ajax apps. |
| Communication channels | Cellular (4G) x 2 |
| Radio signal range | up to 2000 m |
| Power supply external | 4.2–16 V⎓, up to 2 A (Zinc-air battery or external power source.) |
| Power supply internal | 4.2–16 V⎓, up to 2 A (Rechargeable lead-acid and LiFePO4 batteries (not included). Non-rechargeable LTC batteries (not included).) |
| Device operating DC voltage range | 3.5–16 V⎓ |
| Autonomous operation On external battery in full function mode | up to 18 months - On a 12 V⎓, 600 Ah, zinc-air non-rechargeable external battery (not included). |
| Autonomous operation On external battery in Battery saving mode | more than 5 years - On a 12 V⎓, 600 Ah, zinc-air non-rechargeable external battery (not included). |
| Autonomous operation On internal battery in a Battery saving mode | Up to 17 months - on a 7.2 V⎓, 95 Ah, LTC non-rechargeable Internal battery NB (7.2V/95Ah) (not included). Up to 4 months - on a 6.4 V⎓, 27 Ah, LiFePO4 rechargeable Internal battery RB (6.4V/27Ah) (not included). Up to 2 months - on a 12 V⎓, 7 Ah, lead-acid rechargeable internal battery (not included). |
| Dimensions | 196 × 238 × 100 mm |
| Weight | 1,010 g |
| Operating temperature range | from −10 °C to +40 °C |
| Operating humidity | up to 75% |
| Protection class | IP40 |
| Warranty | 24 months |
