AJAX 12V-24V PSU FOR HUB 2 / HUB 2 PLUS REX 2 2Y 59359.94.NC
SKU
432311
Brand
MPN
59359
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$46.00
Buy Now And Earn 46 Reward Points!
Alternative power supply to connect the Ajax hubs and range extenders to a low-voltage power supply
12–24V PSU replaces the bundled 110/230V~ power supply unit. The installer needs one PH1 screwdriver, Installation manual, and 10 minutes to replace the standard power supply of the hub or range extender with an alternative one.
For convenience, the 12–24V PSU comes with a standard power jack and a terminal adapter.
Ideal to be used in Trailers, Trucks, Boats, or external backup battery power supply
Refer to Instructional video below on How to change PSU?
https://www.youtube.com/watch?v=dItCBRw2HeI
| Input voltage | 8 - 32 V⎓ |
| Output voltage | 4.8 V⎓ ± 5% |
| Turn-on voltage | 8 V⎓ ± 2.5% |
| Turn-off voltage | 7–7.5 V⎓ (depending on load) |
| Max input current | up to 1 А |
| Max output current | 1,5 A |
| Temperature range | from -10 °C to +40 °C |
| Humidity | Up to 75% |
| Connection to mains | Socket: 6.5 × 2 mm |
| Plug: 5 5 × 2,1 mm | Plug: 5.5 × 2,1 mm |
| Dimensions | 98 × 70 × 17 mm |
| Weight | 26 g |
| Warranty | Warranty for the Limited Liability Company “Ajax Systems Manufacturing” products is valid for 2 years after the purchase. |
