Module to protect devices on the Fibra line from short circuits and sabotage

Increased security for wired devices with LineProtect Fibra

LineProtect is a module to protect the Fibra line and devices from electrical sabotage.
If an intruder tries to damage the security system and, for example, hits the StreetSiren Fibra with a stun gun, LineProtect will take the hit. All devices between LineProtect and the hub will continue to operate. The module can be installed at any point of the Fibra line. The output line from LineProtect can be up to 2000 meters in length. LineProtect inherits all the advantages of Ajax smart devices: it is easy to control the module from the app, receive event notifications, and configure or test LineProtect remotely.

Protect against electrical shock
LineProtect Fibra protects Ajax hubs and wired devices from sabotage when an intruder causes short circuits, applies 110/230 V~, or uses stun guns. The module monitors the input and output voltage on the Fibra line. If LineProtect detects an abnormal voltage on the line, it activates the fuses and cuts off the power supply to the devices installed between LineProtect and the hub. Note: LineProtect does not protect devices between the module and the end of the line.

Adapt innovative software to any system
LineProtect is designed to respond to threats quickly without giving intruders a single chance to sabotage the security system. We have developed a unique software algorithm to analyse the line to which LineProtect is connected. During the Lines Power Test, the module receives enough information to set its thresholds for detecting a short circuit and normal voltage values. The algorithm considers all critical parameters to select the optimal thresholds for maximum system protection.

Unique wired technology
Fibra is a protocol to ensure fast and secure two-way wired communication between the hub and connected devices. Fibra delivers instant data-rich notifications: security companies and users know which device was triggered, when, and where it happened.
