AJAX CASE D FIBRA(430*400*133)WHITE 2YR 65976.186.WH
Case D
Casing for secure wired connection of Ajax devices
Safe and fast installation
Choose Case with the required number of slots to fit all Ajax devices you want to install. The box for boards is equipped with fasteners to secure the devices. Also, the mounting box has a tamper and cable ducts. Durable latches and holding screws provide quick and reliable fastening. Route cables and secure the devices in the simplest way possible.
Well thought-out design
Quality is the most important thing in today’s security industry. The mounting box for wired protection complies with the international safety standards that you would expect from an Ajax product. The robust casing walls do not deform and retain their integrity, even during drilling. The stiffeners are designed to provide strength and enhance load-bearing safety. In particular, Case D (430) can hold two 18 Ah batteries, weighing a total of about 10 kg. Additionally, the box for boards features a stylish and user-friendly design. It is also specifically crafted to withstand exposure to sunlight.
| Compatibility | LineSplit Fibra, LineProtect Fibra, MultiRelay Fibra, LineSupply Fibra (with a battery up to 18 Ah), Hub Hybrid (4G) |
| Number of devices | up to 8 |
| Plastic holders (type A) | Module Holder (type A) - for LineSplit Fibra, LineProtect Fibra, and MultiRelay Fibra modules. (4 holders supplied with case - additional holders can be purchased separately.) |
| Plastic holders (type B) | Module Holder (type B) - Place two Module Holder (type B) into the casing to accommodate the Hub Hybrid board. Holders are sold separately. |
| Bubble level | To check the inclination angle of the mount during installation. |
| Recesses for drilling | Ø16 mm or Ø20 mm |
| Dimensions | 430 × 400 × 133 mm |
| Weight of Black case | 3,343 g |
| Weight of White case | 3,381 g |
| Operating temperature range | from −10 °C to +40 °C |
| Operating humidity | up to 75% |
| Warranty | 24 months |
