AJAX CASE C FIBRA (260*210*93)BLACK 2YR 67829.186.BL
Case C
Casing for secure wired connection of Ajax devices
Safe and fast installation
Choose Case with the required number of slots to fit all Ajax devices you want to install. The box for boards is equipped with fasteners to secure the devices. Also, the mounting box has a tamper and cable ducts. Durable latches and holding screws provide quick and reliable fastening. Route cables and secure the devices in the simplest way possible.
Well thought-out design
Quality is the most important thing in today’s security industry. The mounting box for wired protection complies with the international safety standards that you would expect from an Ajax product. The robust casing walls do not deform and retain their integrity, even during drilling. The stiffeners are designed to provide strength and enhance load-bearing safety. In particular, Case D (430) can hold two 18 Ah batteries, weighing a total of about 10 kg. Additionally, the box for boards features a stylish and user-friendly design. It is also specifically crafted to withstand exposure to sunlight.
| Compatibility | LineSupply Fibra (with a battery up to 7 Ah) |
| Number of devices | 1 |
| Plastic rails | to secure a module |
| Bubble level | To check the inclination angle of the mount during installation. |
| Recesses for drilling | Ø16 mm or Ø20 mm |
| Dimensions | 260 × 195 × 93 mm |
| Weight of Black case | 997 g |
| Weight of White case | 1,045 g |
| Operating temperature range | from −10 °C to +40 °C |
| Operating humidity | up to 75% |
| Warranty | 24 months |
