Lenovo ThinkSystem SR250 E-2246G 16GB 7Y51A069AU
SKU
391902
Brand
MPN
7Y51A069AU
Warranty
Standard Manufacturer's Warranty
$2,895.00
Buy Now And Earn 2895 Reward Points!
ThinkSystem SR250 E-2246G 16GB
Lenovo ThinkSystem SR250 is an affordable, single-socket 1U rack server for small and medium businesses that need optimized performance and flexibility for future growth, along with enterprise-class reliability, management, and security.
The SR250 server offers a wide range of processors - from Intel Celeron to Intel Xeon E Series. With support for a memory capacity of up to 128 GB and internal storage of up to 32 TB, the SR250 server is an ideal choice for small- to medium-sized business, workgroups, distributed locations, and web-scale workloads.
Guides & Documents
-
Brochure
-
Manual
Network & Communication
| Ethernet Technology | Gigabit Ethernet |
Warranty
| Limited Warranty | 3 Year |
Chipset
| Chipset Manufacturer | Intel |
| Chipset Model | C246 |
Controllers
| Controller Type | Serial ATA/600 |
| RAID Supported | No |
Storage
| Optical Drive Type | No |
| Total Hard Drive Capacity | No |
Display & Graphics
| Graphics Controller Manufacturer | Matrox |
| Graphics Controller Model | G200 |
| Graphics Memory Capacity | 16 MB |
Interfaces/Ports
| VGA | Yes |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 4 |
| Number of USB 2.0 Ports | 1 |
| Number of VGA Ports | 1 |
Miscellaneous
| Package Contents |
|
| Security Features |
|
| Environmentally Friendly | Yes |
| Environmental Certification | RoHS |
| CECP | |
| CELP |
Physical Characteristics
| Weight (Approximate) | 12.30 kg |
| Form Factor | Rack |
| Rack Height | 1U |
| Height | 43 mm |
| Width | 434 mm |
| Depth | 498 mm |
Operating System
| Operating System | No |
| Operating System Supported | SuSE Linux Enterprise Server 15 |
| Red Hat Enterprise linux 7.5 | |
| Windows Server 2019 | |
| Red Hat Enterprise Linux 7.7 | |
| SUSE Linux Enterprise Server 12 SP3 | |
| Red Hat Enterprise Linux 8 | |
| SUSE Linux Enterprise Server 12 SP5 | |
| Red Hat Enterprise Linux 8.1 | |
| Windows Server 2016 | |
| SUSE Linux Enterprise Server 15 SP1 |
Memory
| Error Checking | ECC |
| Maximum Memory Supported | 128 GB |
| Standard Memory | 16 GB |
| Memory Technology | TruDDR4 |
| Number of Total Memory Slots | 4 |
| Number of Occupied Memory Slots | 1 |
| Memory Clock Speed | 2.67 GHz |
Power Description
| Input Voltage | 120 V AC |
| 230 V AC | |
| Plug/Connector Type | C13/C14 |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 1 |
| Hot Swappable Power Supply | Yes |
| Maximum Power Supply Wattage | 450 W |
Processor
| Processor Speed | 3.60 GHz |
| Processor Type | Xeon |
| Processor Model | E-2246G |
| Processor Core | Hexa-core (6 Core) |
| Processor Manufacturer | Intel |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
I/O Expansions
| Number of Internal 2.5" Bays | 8 |
| Number of Total Expansion Bays | 8 |
| Number of Total Expansion Slots | 3 |
| Hot Swappable Bays | Yes |
| PCI Express x4 (Gen 3.x) Slots | 1 |
| PCI Express x8 (Gen 3.x) Slots | 2 |
| Number of SFF Bays | 8 |
| PCI Express Details | 2x PCIe x8 1x PCIe x4 |
General Information
| Product Type | Server |
| Manufacturer Part Number | 7Y51A069AU |
| Manufacturer Website Address | http://www3.lenovo.com/au/en |
| Manufacturer | Lenovo Group Limited |
| Product Model | 7Y51A069AU |
| Product Name | ThinkSystem SR250 7Y51A069AU Server |
| Product Line | ThinkSystem |
| Product Series | SR250 |
| Brand Name | Lenovo |
