Thirdparty POWERBOX POW-13 WM 13.8VDC 7A POWER SUPPLY (100W) & WMBB ENCLOSURE -2YRS

SKU
429762
Brand
MPN
ACPS13.8
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $353.00 Regular Price $405.00
Buy Now And Earn 353 Reward Points!

POWERBOX POW-13 WM 13.8VDC 7A POWER SUPPLY (100W) & WMBB ENCLOSURE -2YRS



BUNDLED COMPONENTS INFO
QTY SKU DESCRIPTION
1 POWERBOX WM ENCLOSURE (375WX362HX110D) -2YRS
1 POWERBOX POW-13 CME 13.8VDC 7A POWER SUPPLY (100W) -2YRS



The PBB2S-13-7-WMBB-K includes the PBB2S-13-7 PSU and the WMBB enclosure. Accepts Batteries 7AH to 17AH (Not included) The PBB2S-13-7 is a 13.8Vdc, 7A off-line battery charger / DC uninterrupted power supply which operate from 100-240Vac mains power. When connected to a valve regulated lead-acid (VRLA) battery, these units provide uninterrupted power to a DC load in the event of mains failure. The PBB2S Series contains a two-step current limited float charger, output over-current and short circuit protection, a self-resetting battery fuse, over-temperature protection, and mains DC OK battery OK and battery fuse fail alarms. The PBB2S is available in a light weight corrosion resistant aluminium chassis mount enclosure. - 12VDC 3.5A power supply for battery backup. - High reliability and high efficiency. - Industrial-grade switching power converter. - Light weight corrosion resistant aluminium enclosure. - Output over current and short circuit protection. - Separate current-limited battery charging output. - Output over voltage protection. - Self-resetting battery fuse. - Over temperature protection. - Mains OK / DC OK - Green LED and alarm contact. - Green Battery OK - Green LED and alarm contact. - Battery Fuse Fail - Red LED. - Dimensions 219 (L) x 114 (W) x 62 mm (D).

Model PBB2S-13-7-WMBB-K
Voltage [V] 190 - 265Vac 1ø
Frequency [Hz] 45 - 65Hz
Current [A] 2.8 max.
Vout 13.8Vdc
Total Power 100W
Itotal 7.0A
Iout 6.0A
Ptot 100W
Dimensions (LxWxH) 375 x 362 x 111.5mm
Battery Configurations (Not included) 1 x 12V 7Ah or 1 x 12V 9Ah or 1 x 12V 17Ah
POWERBOX POW-13 WM 13.8VDC 7A POWER SUPPLY (100W) & WMBB ENCLOSURE -2YRS
