Output
Output Power Capacity
330 Watts / 550 VA
Max Configurable Power
330 Watts / 550 VA
Nominal Output Voltage
230V
Output Frequency (sync to mains)
47 - 63 Hz
Other Output Voltages
220
Waveform Type
Stepped approximation to a sinewave
Output Connections
(4) Australian (Battery Backup)
(4) Australian (Surge Protection)
Output Voltage Tolerance
+/- 5% static and 100% load step
Input
Nominal Input Voltage
230V
Input Frequency
50/60 Hz +/- 5 Hz (auto sensing)
Input Connections
Australian/Chinese
Cord Length
1.83 meters
Maximum Input Current
10A
Batteries & Runtime
Battery Type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time
16 hour(s)
Replacement Battery
APCRBC110
Communications & Management
Control panel
LED status display with On Line : On Battery : Replace Battery and Overload indicators
Surge Protection and Filtering
Surge energy rating
310 Joules
Filtering
Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Data Line Protection
Analog phone line for phone/fax/modem/DSL (RJ-45 connector), Network line - 10/100 Base-T Ethernet (RJ-45 connector)
Physical
Maximum Height
88.00 mm
Maximum Width
180.00 mm
Maximum Depth
302.00 mm
Net Weight
5.50 KG
Shipping Weight
6.20 KG
Shipping Height
128.00 mm
Shipping Width
235.00 mm
Shipping Depth
393.00 mm
Master Carton Units
2.00
Master Carton Dimensions (Length x Width x Height)
405 mm
Master Carton Weight
13.00 KG
Color
Black
SCC Codes
1073130427541 8
Units per Pallet
48.00
Pallet Dimensions
48 inches
# of Layers per Pallet
4
# of Units per Layer per Pallet
20
Pallet Weight
559.09 KG
Environmental
Operating Environment
0 - 40 ?C
Operating Relative Humidity
0 - 95%
Operating Elevation
0-9000 meters
Storage Temperature
-15 - 40 ?C
Storage Relative Humidity
0 - 95%
Storage Elevation
0-9000 meters
Audible noise at 1 meter from surface of unit
40.00 dBA
Conformance
Regulatory Approvals
A-tick, C-tick, CE, TelePermit
Standard Warranty
2 years repair or replace
