- Network StandardIEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.3, IEEE 802.3u, IEEE 802.11i, IEEE 802.11e, IPv4, IPv6
- Product SegmentAC750 complete AC performance : 300+433 Mbps
- Wi-Fi Data Rate802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 433 Mbps - xDSL Data RateVDSL2/ADSL2+/ADSL2/ADSL multimode
Support Annex A/B/I/J/L/M
Support all VDSL2 profiles -8a, 8b, 8c, 8d, 12a, 12b, 17a and 30a
VDSL2 interface compliance with ITU-T G.993.2
ITU-T G.992.1 (G.dmt), Annex A, and B Compliant
ITU-T G.992.2 (G.lite), Annex A, and B Compliant
ANSI T1.413 Compliant
ITU-T G.992.3 (ADSL2) Compliant, Annex A, B, L, and M
ITU-T G.992.5 (ADSL2+) Compliant, Supporting Annex A, B, and M
ITU-T G.993.2 Compliant, Annex A, B
ITU-T G.993.5 (Vectoring)
ITU-T G.998.4 (G.inp) Improved impulse noise protection
ATM and PTM (dual-priority)
VDSL2 Upstream: 150Mbps, Downstream: 200Mbps
ADSL2+ Upstream: 3.3Mbps, Downstream: 24Mbps
ADSL2 Upstream: 3.5Mbps, Downstream: 12Mbps - FeaturesDHCP server, firewall/NAT, DynDNS
VPN server(PPTP/OpenVPN)
VPN client(PPTP/L2TP/OpenVPN)
Dual WAN Fail over/Fail back/Load balance
Traffic monitor/Quality of Service (QoS)
DSL spectrum
IPTV(VDSL/ADSL WAN)
DSL feedback mechanism
Save/Resotre configuration file
WiFi Bandwidth Limiter
AiProtection - AntennaExternal dBi antenna x 4
- LED IndicatorPower, Internet, LAN x 4, xDSL, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi, USB x 1
- ButtonWPS Button, Reset Button, Power Button, Wireless on/off Button
- Ports1 x RJ11 for xDSL
4 x RJ45 10/100/1000 BaseT for LAN
1 x RJ45 10/100/1000 BaseT for WAN - USB PortsUSB 2.0 x 1
- USB ApplicationsPrinter Server
FTP Server
Download Master
3G/4G sharing - Router Special Features3G/4G data sharing, AiCloud, Printer server, Download Master, AiDisK, Multiple SSIDs, Parental Control
- Operating Frequency2.4GHz
5GHz - Operation Channel13 Europe (ETSI)
- Memory128MB NAND flash/128MB DDR3
- Output Powerac mode : 17 dBm
b mode : 20.5 dBm
g mode : 18.5 dBm
n mode : 17 dBm
a/n mode : 19 dBm - Security64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK
- ManagementWeb-based GUI configuration
Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI
UPnP IGD 1.0
Auto VPI/VCI detection
Configuration backup and restore
Diagnostics
Log & Trace function - Utilities- Download master:
.Support BT, NZB, HTTP, ED2K
.Support encryption, DHT, PEX and magnet link
.Upload and download bandwidth control
.Download scheduling
- Media server:
.Image: JPEG
.Audio: mp3, wma, wav, pcm, mp4, lpcm, ogg
.Video: asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
- Printer Server:
.Multifunctional printer support(Windows only)
.LPR protocol support - VPN SupportIPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server
OpenVPN server
PPTP client
L2TP client
OpenVPN client - Power AdapterAC Input : 110 ~240 V(50~60HZ)
DC Output : 12 V/1.5 A
Power Consumption : 18 W Max. - CertificatesCE, Telepermit, RCM
- Dimensions20.7 x 14.9 x 3.6 ~ cm (WxDxH) (Without Bezel)
- Weight360 g (Device Only)
- OS SupportWindows® 10
Windows® 8.1
Windows® 8
Windows® 7
Windows® Vista
Windows® 2000
Windows® XP
Mac OS X 10.1
Mac OS X 10.4
Mac OS X 10.5
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8 - Package ContentDSL-AC52U Dual-band 802.11ac VDSL/ADSL Modem Router
RJ-45 cable
RJ-11 cable
Support CD(User manual and utility)
Power adapter
Warranty card
Quick start guide
Splitter (varies with regions)
Asus Dsl-ac52u Adsl/ Vdsl Ac750 Dual-band Wireless Modem Router 1x Gigabit Wan 4x Gigabit Lan
SKU
252791
Brand
Warranty
Standard Manufacturer's Warranty
No Longer Available
Special Price $118.00 Regular Price $136.00
Buy Now And Earn 118 Reward Points!
QUICK OVERVIEW
1x USB (NBN/ Fibre Ready) - Great Wireless Coverage DSL-AC52U
AC750 Dual-Band ADSL/VDSL Gigabit Wi-Fi Modem Router
- 2-in-1 design
Dual WAN ports for dual usage – Wi-Fi router and DSL modem - Great compatibility
Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services - PPTP/Open VPN server and VPN client support
Remote access to your home network via encrypted and private connection - Parental Controls
Monitor and filter internet activities for your families and children - Multi-purpose USB 2.0 port
Supports file sharing, printer sharing and 3G/4G support - ASUS AiCloud 2.0
Access, sync, share and stream your files anywhere, on any internet-connected device
Consistently Praised for Networking Excellence!

Readers’ Choice, 6 Years Running! (2012-2017)
“No brand is more likely to be recommended than ASUS. The company receives excellent marks for their ease of setup and reliability.”– PC Magazine >>Learn more.

Recommended Excellence Award for Best Router Brand, PC Pro Technology Excellence Awards 2016.
Future-proofed versatility with 802.11ac wireless speeds
The ASUS DSL-AC52U is a ADSL/VDSL 802.11ac Wi-Fi modem router, with combined dual-band data rates of up to 733Mbps. On the 5GHz band, 802.11ac gives 433Mbps wireless data rates, while 2.4 GHz 802.11n performance supports 300Mbps. Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services, the top specification completes future-proofing.
ASUS AiRadar enhances the Wi-Fi stability and improves coverage up to 150%*. Most importantly, the universal beamforming not only works on 802.11ac clients, but also 802.11a/b/g/n clients. Equipped with powerful hardware NAT acceleration and built-in Gigabit Ethernet, the DSL-AC52U gives you full Gigabit internet performance, with a WAN-to-LAN throughput performance of over 900 Mbps.
USB 2.0 port allows the DSL-AC52U to share printer and scanner over a network, and it can also operate as high-speed NAS (Network Attached Storage) device when external storage is connected.
The easy-to-use ASUSWRT graphical user interface unlocks the power of DSL-AC52U giving robust control to optimize your network for you. 30-second setup and easy traffic management means even network newbies can enjoy its sophisticated features, while power users will love its IPv6 support, multiple wireless SSIDs and encrypted VPN access.
Enhanced signal range and stability
ASUS AiRadar intelligently improves wireless connections by using exclusive ASUS RF fine-tuning. This ensures extended coverage, increases dynamic data speed, and enhances stability.

Total flexibility with DSL, Ethernet or 3G/4G LTE Internet connections
DSL-AC52U has multiple ways to connect to the Internet, with a choice of DSL, Ethernet or 3G/4G LTE*. You can use DSL-AC52U as a DSL modem Wi-Fi router or a standalone Wi-Fi router according to your needs. And with the ability to switch instantly between connections if one fails (and switch back again when it’s fixed) or combine multiple connections for more bandwidth, it’s perfect for reliable, always-on internet connectivity. *Requires compatible USB dongle

Gigabit Internet browsing with hardware NAT
Equipped with a powerful hardware NAT acceleration engine and built-in Gigabit Ethernet, the DSL-AC52U gives you full Gigabit performance. Its WAN-to-LAN throughput performance is over 900 Mbps, which is more than 4.5 times that of traditional software-based NAT Gigabit routers. This reduces the possibility of bottlenecks on fast internet connections.


Add external storage, printers, and other devices to your network
Make DSL-AC52U your media and device center. With built-in two USB ports, connect external storage drives, printers, scanners and many other USB-enabled devices to share with your networked PCs. Having your devices networked, lets you access them easier than ever before.
Robust control and optimization with DSL ASUSWRT
With the DSL-ASUSWRT dashboard UI, setup, monitor, and control network applications all in one intuitive area. The whole-new dashboard interface lets you manage all clients and settings via a single graphical interface, and provides 1-click updates. Try our ASUSWRT.
ASUS AiCloud – Your world on demand
ASUS AiCloud keeps you connected to your data wherever and whenever you have an internet connection. It links your home network and online web storage service and lets you access it through the AiCloud mobile app on your iOS or Android smartphone or through a personalized URL in a web browser. Learn more.


Download and stream anywhere
Download Master and enhanced media server let you download and play multimedia files stored on router-attached USB storage on a wide range of compatible devices such as PC, pad, PS4, Xbox, and smart TV. Download Master can also download files while your PC is turned off, and allows you to manage and monitor download status remotely.
Better online multitasking at up to 300,000 sessions
Massive online multitasking at up 300,000 concurrent data sessions gives you 20 times the capacity of mainstream routers, allowing for great performance with no slowdown even during heavy traffic sessions. Multiple downloads occur at the same time to create a smoother user experience. More data sessions translate into quicker and buffer-less HD streaming plus lag-free online gaming even while you download content, so you can do more without compromising your online lifestyle.
VPN server and client for encrypted remote connection
With the virtual private network (VPN) server and VPN client, you can access your home network remotely or surf the internet with encryption, no need for paid VPN services or a dedicated VPN server.

Keep Up to Date!
Remember to always keep your device’s firmware up to date so you can benefit from the very latest service and security enhancements — and get exciting new features!
AC750 Dual-Band ADSL/VDSL Gigabit Wi-Fi Modem Router
2-in-1 design
Dual WAN ports for dual usage – Wi-Fi router and DSL modem
Great compatibility
Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services
PPTP/Open VPN server and VPN client support
Remote access to your home network via encrypted and private connection
Parental Controls
Monitor and filter internet activities for your families and children
Multi-purpose USB 2.0 port
Supports file sharing, printer sharing and 3G/4G support
ASUS AiCloud 2.0
Access, sync, share and stream your files anywhere, on any internet-connected device
◎ IEEE 802.11 ac/b/g/n
◎ GbE LAN*4, RJ11*1,GbE WAN*1
◎ 1*USB2.0
◎ ASUSWRT
◎ AiCloud
● Gb LAN Port x4; Gb WAN Port x1 ; 2.4Ghz & 5Ghz
● Flash 128MB / DDR3 RAM 128MB
● ASUSWRT UI Pro: web-based parental control/ ProQoS configured by IP/by MAC
● Download Master: support up to 15 files downloading simutaniously
● AiCloud
2-in-1 design
Dual WAN ports for dual usage – Wi-Fi router and DSL modem
Great compatibility
Compatible with ADSL2/2+, ADSL, VDSL2, fiber and cable services
PPTP/Open VPN server and VPN client support
Remote access to your home network via encrypted and private connection
Parental Controls
Monitor and filter internet activities for your families and children
Multi-purpose USB 2.0 port
Supports file sharing, printer sharing and 3G/4G support
ASUS AiCloud 2.0
Access, sync, share and stream your files anywhere, on any internet-connected device
◎ IEEE 802.11 ac/b/g/n
◎ GbE LAN*4, RJ11*1,GbE WAN*1
◎ 1*USB2.0
◎ ASUSWRT
◎ AiCloud
● Gb LAN Port x4; Gb WAN Port x1 ; 2.4Ghz & 5Ghz
● Flash 128MB / DDR3 RAM 128MB
● ASUSWRT UI Pro: web-based parental control/ ProQoS configured by IP/by MAC
● Download Master: support up to 15 files downloading simutaniously
● AiCloud
