Network Standard
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac,
IPv4, IPv6
-
Product Segment
AC2900 ultimate AC performance : 750+2167 Mbps
-
Coverage
Very large homes
-
Data Rate
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 450 Mbps
802.11ac : up to 1734 Mbps
1024QAM (2.4GHz) : up to 750 Mbps
1024QAM (5GHz) : up to2167 Mbps
-
Antenna
External detachable antenna x 3
Internal antenna x 1
-
Transmit/Receive
MIMO technology
2.4 GHz 3 x 3
5 GHz 4 x 4
-
Processor
1.8 GHz dual-core processor
-
Memory
256 MB Flash
512 MB RAM
-
Wi-Fi Technology
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth
-
Operating Frequency
2.4 GHz / 5 GHz
-
Encryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise ,
WPA2-Enterprise , WPS support
-
Firewall & Access Control
Access control：Parental control, Network service filter, URL filter,
Port filter
-
Management
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger,
Port Forwarding, DMZ, System Event Log
-
VPN Support
IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server
OpenVPN server
PPTP client
L2TP client
OpenVPN client
-
WAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE
supported), PPTP, L2TP
-
Utilities
Router setup wizard; Firmware restoration; Device discovery; printer
setup utility
-
Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for 10/100/1000/Gigabits BaseT
for LAN x 4
USB 2.0 x 1
USB 3.0 x 1
-
Features
MU-MIMO
Traffic Analyzer
Adaptive QoS
WTFast Gamers Private Network
AiProtection
Parental Control
Guest Network : 2.4 GHz x 3, 5 GHz x 3
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
- Image : Jpeg
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
- Multifunctional printer support (Windows only)
- LPR protocol support
Download Master
- Support bt, nzb, http, ed2k
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
AiDisk file server
- Samba and FTP server with account management
IPTV support
Roaming Assist
-
Button
WPS Button, Reset Button, Power Button, Wireless on/off Button, LED
on/off Button
-
LED Indicator
Power x 1
Wi-Fi x 2
WAN x 1
WPS x 1
LAN x 4
-
Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 1.75 A current
-
OS Support
Windows® 10
Windows® 8
Windows® 7
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
Linux
-
Dimensions
220 x 160 x 83.3 ~ mm (WxHxD) (Without Bezel)
-
Weight
872 g
-
Operation mode
Wireless router mode
Access point mode
Media bridge mode
