Audio |
Realtek® ALC887 codec High Definition Audio 2/4/5.1/7.1-channel * To
configure 7.1-channel audio, you need to open the audio software and
select Device advanced settings > Playback Device to change the default
setting first. Please visit GIGABYTE's website for details on
configuring the audio software. |
Chipset |
Intel® B460 Express Chipset |
Form Factor |
Micro ATX Form Factor; 22.6cm x 18.5cm |
I/O Connectors |
1 x PS/2 mouse port 1 x PS/2 keyboard port 1 x D-Sub port 1 x DVI-D port
4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio
jacks |
Integrated CPU Graphics |
Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub
port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DVI-D port,
supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does
not support D-Sub connection by adapter. Maximum shared memory of 512 MB |
LAN |
Realtek® GbE LAN chip (10/100/1000 Mbit) |
Memory/Type/Bus/Max. |
Intel® Core™ i9/i7 processors: Support for DDR4 2933/2666/2400/2133 MHz
Intel® Core™ i5/i3/Pentium®/Celeron® processors: Support for DDR4
2666/2400/2133 MHz 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB
single DIMM capacity) of system memory |
PCI Slots |
Expansion Slots 1 x PCI Express x16 slot, running at x16 2 x PCI Express
x1 slots (The PCI Express slots conform to PCI Express 3.0 standard.) |
Processor Support |
Support for 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7
processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel®
Pentium® processors/Intel® Celeron® processors in the LGA1200 package L3
cache varies with CPU |
Raid |
Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
RAM Type/Bus/Max. |
Intel® Core™ i9/i7 processors: Support for DDR4 2933/2666/2400/2133 MHz
Intel® Core™ i5/i3/Pentium®/Celeron® processors: Support for DDR4
2666/2400/2133 MHz 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB
single DIMM capacity) of system memory |
Socket |
LGA1200 |
Storage Interface |
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe
x4/x2 SSD support) 6 x SATA 6Gb/s connectors Support for RAID 0, RAID 1,
RAID 5, and RAID 10 * Refer to "1-7 Internal Connectors," for the
installation notices for the M.2 and SATA connectors. Intel® Optane™
Memory Ready |
Warranty |
3 Years |
Weight |
|
BIOS |
1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM
2.0, SM BIOS 2.7, ACPI 5.0 |
H/W Monitoring |
Voltage detection Temperature detection Fan speed detection Overheating
warning Fan fail warning Fan speed control * Whether the fan speed
control function is supported will depend on the cooler you install. |
Operating System |
Support for Windows 10 64-bit |
Unique Features |
Support for APP Center * Available applications in APP Center may vary
by motherboard model. Supported functions of each application may also
vary depending on motherboard specifications. @BIOS Ambient LED EasyTune
Fast Boot Game Boost ON/OFF Charge Smart Backup System Information
Viewer Support for Q-Flash Support for Xpress Install |
USB |
Chipset: 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports
available through the internal USB headers) 6 x USB 2.0/1.1 ports (2
ports on the back panel, 4 ports available through the internal USB
headers) |
