Specifications

Printer Functions

Hide
Ink Droplet Size 5pl (C/M/Y), 11pl (PGBK)
Printing Resolution (Horizontal x Vertical) 600 (horizontal) x 1200 (vertical) dpi
Print Speed B&W: 24 ipm in approx. 6 seconds (FPOT), Colour: 15.5ipm in approx. 7 seconds (FPOT)
Paper Capacity Plain paper: A4 = 250 Sheets (Cassette 1 upper), A4 = 250 sheets (Cassette 2 lower) , 4”x6” photo paper = 20 Sheets, European DL/ US Com = 10 Sheets
Paper Sizes 4" x 6", 5" x 7", 8" x 10", A4, A5, Envelope (DL, COM10), Letter
Supported Paper Weights Plain Paper: 64-105 g/m2 , Canon specialty paper: max paper weight : approx. 275 g/m2 (Photo Paper Plus Glossy II PP-201)
Network

Hide
Protocol SNMP (standard MIB), TCP/IP
Wireless LAN Network Type IEEE802.11n/IEEE802.11g/IEEE802.11b
Frequency Band / Channel 2.4GHz / 1-13
Wireless LAN Data Rate indoor 50m (depends on the transmission speed and conditions)
Wireless LAN Range WEP64/128bit, WPA-PSK(TKIP/AES), WPA2-PSK(TKIP/AES)
Camera/Memory Card Printing Print/Scan with any Apple or Android devised through the Inkjet/ SELPHY App. Cloud integration with Cloud Print Apps. Apple AirPrint supported
PC Interface Available
Copier

Hide
Speed sFCOT A4/ LTR Colour Simplex Approx. 11 sec ADF ESAT A4/ LTR B&W Simplex Approx. 22 ipm ADF ESAT A4/ LTR Colour Simplex Approx. 11.5ipm
Multiple Copy Max. 99 pages
Scanner

Hide
Scanner Type Flatbed and ADF
Scanning resolution 1200 x 1200 dpi
Scanning Speed Simplex: Approx. 19 ipm B&W/ Approx. 16 ipm Colour (scESAT)
Duplex: Approx. 23 ipm B&W Approx. 23 ipm Colour (scESAT)
Scanning Bit Depth (Input/ Output) Grayscale; 16bit/8bit Colour: 48bit/24bit (RGB each 16bit/8bit)
Fax Features

Hide
Fax Resolutions Black: 8pels/mm x 3.85lines/mm (Standard), 8pels/mm x 7.7lines/mm(Fine), 300dpi x 300dpi (Extra Fine), Colour: 200dpi × 200dpi
Transmission Speed Black: Approx. 3 seconds (33.6kbps), Colour: Approx. 1 minute (33.6kbps)
Modem Speed Maximum 33.6kbps (Automatic fall back)
Fax Memory Approx. 250 pages
PC Fax Type Windows: Available, Mac: Available
PC Fax Destination Number 1 location
MAXIFY Cloud Link

Hide
From smartphone or tablet Available
From printer Available
Print from Email Available
Google Could Print Available
Apple Air Print Available
MAXIFY Printing Solutions Available
Cloud Apps Facebook, Twitter, Flickr, Canon Image Gateway, Picasa, Photobucket, Evernote, Dropbox, Google Drive and One Drive, Concur
General Features

Hide
LCD Screen LCD (3.5 inch / 8.8 cm TFT colour/Touch)
Intelligent Touch System Available
Operating System Windows XP SP3 (32 Bit only), Windows Vista SP2, Windows 7, Windows 7 SP1, Windows 8, Windows 8.1, Windows 10.0, Mac OS X 10.7.5 or later, Windows 10.0, Mac OS EI X Capitan 10.11
Power Source AC100 - 240V, 50/60Hz
Power Consumption Standby (scanning lamp is off) USB connection to PC: approx. 0.9W, OFF: Approx. 0.3W, Copying (USB connection to PC) approx. 27W
Dimensions (W x D x H) Approx. 463 x 394 x 351 mm
Weight Approx. 12.9kg
Notes

Hide
Barcode 4549292052619
general Speed ad price claims made using test print ISO / IEC 24734 which represents a standard A4 print. This Print is black and white and used Genuine Canon XL inks as RRP $57.99 as at July 2016. It was produced under test conditions and speeds are approximate
Print Speeds Document Print Speeds are averages of EAST in Office Test of the default simplex mode, ISO/IEC 24734, Print speed may vary depends on system configuration, interface software, document complexity, print mode, page, coverage, type of paper used etc
Copy Speeds Copy Speeds are the average of sFCOT and sESAT, ISO/IEC29183, Copy speed may vary depending on document complexity, copy mode, page coverage, type of paper used etc.. and does not take into account warming-up time.
Scanning Resolution Optical resolution is measure of maximum hardware sampling resolution, based on ISO 14473 standard.
Scanning Speed Colour documents scan speed is measured with ISO/IEC29183 target A. Scan speed indicates the time measured between pressing the scan button of the scanner driver and the on-screen status display turns off. Scan speed may vary depending on system configura
Fax Resolutions Black and white document fax transmission speed is based default settings using Canon Colour Fax Test Sheet. Actual transmission speed may vary depending on document complexity, fax settings at receiving end and line conditions etc.
Fax Transmission / Reception Memory Page count is based on ITU-T No.1 chart or Canon FAX standard Chart No. 1.
Frequency Band / Channel 1-11 in US, CND, LTN, BRA, TW and HK
Scanner Type When scanning or copying a certain volume of documents continuously from the ADF, the printer may vary depending on-scan setting such as colour/mono, resolution and so on. In case if the default settings (scan or copy in colour, 300dpi), the printer switc
Printer Features Some printer functions may not work unless a full set of Genuine inks are used. Some functions require an internet connection or WiFi – USB cable not included.
