DESCRIPTION
Utilizing both Gigabit technology and D-Link Green™ technology, the D-Link DGS-1024D is an ideal switch for the eco-minded and competitive small business.The DGS-1024D provides three key benefits through its cutting edge, innovative D-Link Green eco-friendly technology:
Reduces power consumption & creates less heat
Extended product life
Reduces operating costs
POWER SAVINGS BY NUMBER OF CONNECTED PORTS AND LINK STATUS
Computers do not require Internet access all the time; neither do switches utilize all ports at all times. When a computer or network equipment is shut down, switches often remain on and continue to consume considerable amounts of power. With D-Link Green Technology, D-Link switches can automatically detect link status and reduce power usage of ports that are idle. Computers or any connecting parties set to standby mode (not power off), however, will not provide significant power savings.
POWER SAVINGS BY CABLE LENGTH
D-Link Green verified switches have the ability to analyze the length of any Ethernet cable connected to them for adjustment of power usage accordingly. Shorter lengths require less power.
OVERALL POWER SAVINGS PER DAY
For a traditional switch, power consumption remains constant even when the ports are not in use. In a standard workday scenario where PCs are used for 10 hours a day and powered off 14 hours a day, and connected to the switch using 20 meter cables, D-Link Green Technology can save up to power used for each system.
Get the blazing speed of Gigabit Ethernet with the D-Link GigaExpress DGS-1024D, an 24-port 10/100/1000Mbps Gigabit Switch that delivers power, performance, and reliability in one cost-effective, space-saving design. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality.
Power users in the office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly. The versatile and compact 1RU height design of the DGS-1024D enables the device to be rackmounted in a standard 19 inch rack, while conserving valuable rack space.
POWER-PACKED
It features a non-blocking switching architecture that filters and forwards packets at full wire-speed for maximum throughput. An 8K MAC address table provides scalability for even the largest networks. Address learning and aging, 802.3x Flow Control for full-duplex mode, and back pressure flow control for half-duplex mode alleviates traffic congestion and ensures reliable data transmission.
Designed using industry standards, it is compatible with virtually all 10, 100, and 1000Mbps Ethernet devices and other vendor equipment. The D-Link DGS-1024D 10/100/1000 Mbps Gigabit Switch protects your existing network investments while providing you with a straightforward migration path to faster Gigabit speeds.
EASY TO USE
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.
The switch also features diagnostic LEDs which display status and activity, allowing you to quickly detect and correct problems on the network. Every port also supports a cable diagnostic feature that helps to detect cable related problems.
Note: Switch uses switching power adapter. The cable length which PCs are connected to switch is 20m cables.
Maximum power savings when compared to a D-Link conventional switch. Uses up to 45% less energy when connected devices are powered down and up to 25% less energy when connected devices are used 10 hours and powered down 14 hours over a 24-hour period, when connected via 20 meter Ethernet cables.
D-Link Green Technology features available on hardware version C1 or later
FEATURES
D-Link Green Technology
48Gbps Switching Capacity
Desktop or Rack Mountable Design
Non-blocking Architecture
Brand
D-Link
Model
DGS-1024D

Spec
Format
Rackmount
Standards
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network Management Type
Unmanaged
Jumbo Frames
Yes
Ports
24 x RJ45
Speed
10/100/1000Mbps
MAC Address Table
8K
Buffer Memory
On ship: 500KB Buffer Memory per Device
Switching Method
Store and Forward
PoE
No
Stackable
No
SNMP
No
QoS
Yes
LACP
No
Layer
1
Port Mirroring
No
Module Support
No
LEDs
Per Unit: Power
Per Port: Activity/Link, Speed
VLAN Support
No
Power
100-240VAC, 50/60 Hz Internal Universal Power
Dimensions
11.0" x 7.1" x 1.7"
Weight
3.99 lbs.
Temperature
0ºC to 40ºC (32ºF to 104ºF)
Humidity
5% - 95%, Non-condensing

Features
Features
Green Ethernet Technology:
Reduces power consumption & creates less heat
Extended product life
Reduces Operating Costs

Power Savings by Number of Connected Ports and Link Status
Power Savings by Cable Length
Overall Power Savings Per Day
Power-Packed
Easy to use

48Gbps Switching Capacity
Desktop or Rack Mountable Design
Non-blocking Architecture

Packaging
Package Contents
DGS-1024D
User Manual
Power Cord
Rack mount kit
