Technical Specifications

Camera Hardware Profile

• 1/2.7" Megapixel progressive CMOS sensor
• 16 ft night vision with infrared LEDs
• Minimum illumination:
  • Color (Day Mode), IR LEDs off: 2.2 lux
  • B/W (Night Mode), IR LEDs off: 1.6 lux
  • B/W (Night Mode), IR LEDs on: 0 lux
• Built-in Infrared-Cut Removable (ICR) filter module
• Fixed length 2.7mm
• Aperture: F2.4
• Angle of view:
  • (H) 137°
  • (V) 71°
  • (D) 167°
• Built-in microphone
• Built-in speaker

Image Features

• Configurable image size
• Pre-event snapshot and recording
• Configurable Sound level detection
• Configurable motion detection windows

Video Compression

• Simultaneous H.264/MJPEG format video compression
• JPEG for still images

Video Resolution

• Main Profile: 1080p (1920 x 1080) at up to 30 fps
• Second Profile: 720p (1280 x 720) up to 15 fps

Audio Compression

• AAC

Connectivity

• 802.11b/g/n wireless with WPA/WPA2 encryption
• Operates on 2.4 GHz band
• MicroSD card slot
• Bluetooth 2.1/3.0/4.0

Network

Network Protocols

• IPv4, IPv6, ARP, TCP, UDP, ICMP
• DHCP Client
• DNS Client
• RTP, RTSP
• HTTPS
• Bonjour

Security

• WPA-PSK
• WPS2-PSK

System Integration

Event Management

• Motion detection
• Sound level detection
• Push notification

Remote Management

• Configurable accessible via mydlink™ app

Mobile Support

• mydlink app for iPhone, iPad, Android phone and tablet

General

Dimensions (W x D x H)

• 4.31 x 2.6 x 2.6 inches

Weight

• 0.23 lbs ± 5% (with stand)

Power

• 5 V DC / 1.2 A through external power adapter
• Power adapter: 100 to 240 V AC, 50/60 Hz
• Power Consumption: 5.5 watts maximum ± 5%

Temperature

• Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -20 to 70 °C (-4 to 158 °F)

Humidity

• Operating: 20% to 80% non-condensing
• Storage: 5% to 95% non-condensing

Certifications

• CE
• CE LVD
• FCC Class B
• ICES

⚫High quality 1080p Full HD resolution
⚫137-degree viewing angle
⚫Bluetooth setup
⚫Built-in IR LEDs to capture video in up to 5m of complete darkness
⚫Motion and sound detection
⚫Pinch to Zoom
⚫H.264 support for the best video streaming performance
⚫mydlink app lets you remotely view, receive notifications, save snapshots and video clips to your mobile device
⚫microSD card slot lets you backup video and images to a flash card
⚫mydlink Cloud Recording subscription
⚫Works with the Google Assistant, Amazon Alexa and IFTTT
