AXIS D8308 FIBER SWITCH, 8X SFP PORTS, NO POE 03063-006
SKU
432208
Brand
MPN
D8308
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Special Price $2,621.00 Regular Price $3,014.00
Buy Now And Earn 2621 Reward Points!
Axis D8308 8-Port Fiber Aggregation Switch Developed for long distance fiber installations. Equipped with eight SFP+ ports, two additonal SFP28 ports and one RJ45 console port for configuration.
- 8 SFP+ and 2 SFP28 ports
- For long distance fiber installations
- Easy installation and configuration
- Optimized for surveillance solutions
Unique web graphic user interface
| Network function | Full L2 switching features including L3 features: IPv4/IPv6 static route, RIP, and OSPF |
| Network protocols | IPv4, IPv6, HTTP, HTTPS, QoS Layer 3 DiffServ, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3, DNS/DNSv6, NTP, TCP, UDP, IGMPv1/v2/v3, ICMP, DHCP, ARP, SSH, CDP, RADIUS, TACACS+, Syslog, IEEE 802.1X, 802.1Q (VLAN), LLDP, LLDP-Med, STP, MSTP, RSTP, LACP, RIP v1/v2, OSPF v2/v3 |
| Throughput | 193.44 Mpps |
| Switching capacity | 260 Gbps |
| MAC table | 32 K |
| Jumbo frames | 10240 Bytes |
| EMC | CISPR 32 Class A, EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 Australia/New Zealand: RCM AS/NZS CISPR 32 Class A Canada: ICES(A)/NMB(A) Japan: VCCI Class A USA: FCC Part 15 Subpart B Class A |
| Safety | CAN/CSA C22.2 No. 62368-1 ed. 3, IEC/EN/UL 62368-1 ed. 3, RCM AS/NZS 62368.1:2022 |
| Network security | IEEE 802.1X, HTTPS encryption, TLS v1.2, X.509 Certificate PKI, Access Control List (ACL), port security, IP source guard, storm control, private VLAN, DHCP snooping, ARP inspection, password protection, loop protection |
| Casing | Steel, Black |
| Power | 100-250 V AC 50/60hz |
| Connectors | SFP+ 10GBASE-LR/SR SFP+ (8x) Data ports/Uplink 25GBASE-LR/SR SFP28 (2x) Power Power connector port (1x) Console RJ45 (1x) |
| Surge protection | Network ports: 1kV AC lines: 2 kV |
| Operating conditions | 0 to 50 °C (-32 °F to 122 °F) Humidity 0–95% RH (non-condensing) |
| Weight | 2580g (5.67 lb) |
| Warranty | 5 Years |
AXIS D8308 FIBER SWITCH, 8X SFP PORTS, NO POE
