TP-Link ER701-5G Outdoor Omada 5G Gateway with Dual Nano SIM Support, PoE Power Input, 2.5G Ethernet Port, Enterprise Routing, VLAN, Firewall, and Omada Cloud Management

Device
•Outdoor 5G Gateway / Router Dual
•Nano SI
•PoE powered
• Omada-managed
Cellular – 5G NR
• Bands:
n1 / n3 / n5 / n7 / n8 / n20 / n26 / n28 / n38 / n40 / n41 / n75 / n76 / n77 / n78
• Frequencies:
700 / 800 / 850 / 900 / 1500 / 1800 / 2100 / 2300 / 2500 / 2600 / 3500 / 3700 MHz
• SA:
7.01 Gbps ↓ / 1.25 Gbps ↑
•NSA: 4.5 Gbps ↓ / 730 Mbps ↑
Cellular – 4G LTE
• FDD:
B1 / B3 / B5 / B7 / B8 / B20 / B26 / B28 / B32
•TDD: B38 / B40 / B41 / B42 / B43
• Speed: 1.6 Gbps ↓ / 211 Mbps ↑
Cellular – 3G
• WCDMA:
B1 / B5 / B8
SIM
•1 × Dual Nano SIM slot
• Failover supported
Ethernet
•1 × 2.5G RJ45
•10 / 100 / 1000 / 2500 Mbps
•PoE:
•802.3at (42–57 V, 0.6 A)
• Passive 48 V
Wireless (Local)
• 2.4 GHz only
• 802.11 b / g / n
• 150 Mbps max
• WPA / WPA2-Personal
• 1 SSID
•TX power control
• Auto channel selection
Routing / Switching
•Static routing
• OSPF (Standalone)
• Bridge VLAN
• 802.1Q VLAN
• Multi-Net interfaces
NAT / Firewall
• Multi-Net NAT
• Virtual server
• Port triggering
• NAT-DMZ
•ALG: FTP / SIP / IPSec / PPTP / H.323
• UPnP
•Stateful ACL
Storage / Memory
•4 GB eMMC
•2 GB LPDDR4x
Power Max consumption:
•15.3 W
Physical Dimensions:
•183 × 110 × 36 mm
• Wall / pole / window mount
• Waterproof kit included

Warranty Period: 3-Year
