Technical Specifications

Camera Hardware Profile

• 1/2.7" progressive CMOS sensor
• Minimum illumination: B/W (Night Mode), IR LEDs on:0 lux
• Minimum object distance: 20”
• Lens focal length: 2.39mm
• Aperture: F2.0
• 16 ft IR Illumination distance
• Angle of view:
  • (H) 98°
  • (V) 52°
  • (D) 114°
• Infrared-Cut Removable (ICR) Filter
• Built-in microphone
• Built-in Speakers

Image Features

• Configurable video resolution
• Configurable sound detection level
• Configurable motion detection windows

Video Compression

• Simultaneous H.264 format compression
• JPEG for still images

Video Resolution

• Main Profile: 1080p (1920 x 1080) at up to 30 fps
• Second Profile: 720p (1280 x 720) at up to 15 fps

Audio Support

• MPEG-2 AAC LC

Pan/Tilt

Pan Range

• -170° to + 170° (total 340°)

Tilt Range

• -20° to +90° (total 110°)

Angular Velocity

• 16° per second

Network

Connectivity

• 10/100 BASE-T Fast Ethernet port
• Single-band 1T 1R mode supports a maximum data rate of 72.1 Mbps (PHY rate) using the 20 MHz band
• 802.11 b/g/n wireless with WPA/WPA2 encryption
• Bluetooth 4.0
• microSD slot

Network Protocols

• IPv4, IPv6, ARP, TCP, UDP, ICMP
• DHCP Client
• DNS Client
• Bonjour
• HTTPS
• RTSP/SRTP

System Integration

Event Management

• Motion detection
• Sound detection
• Cloud recording
• SD card recording
• Manually taken snapshots & Video clips are saved to mobile device
• Push notifications

Mobile Support

• mydlink® app for iPhone, iPad, iPod touch, and Android devices

Physical

Environment

• For indoor use only

Weight

• 0.73 lbs

Power Adapter

• Input: 100 to 240 V AC, 50/60 Hz
• Output: 5 V DC / 2 A, (Micor-USB)

Power Consumption

• Maximum: 8.43 W ± 5%

Temperature

• Operating: 32 to 104 °F (0 to 40 °C)
• Storage: -4 to 158 °F (-20 to 70 °C)

Humidity

• Operating: 20% to 80% non-condensing

Certifications

• CE
• CE LVD
• ICES
• FCC Class B
• RCM

Dimensions (W x H x D)

• 4.38 x 5.26 x 4.58 inches
