Gigabyte UD750GM Ice PG5 750W Atx Psu Power Supply 80+ Gold >90% Black Flat Cables Single +12V Rail Japanese >100K Hrs (New) GP-UD750GM PG5 ICE
SKU
431911
Brand
MPN
GP-UD750GM PG5 ICE
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$154.00
Buy Now And Earn 154 Reward Points!
Gigabyte UD750GM ICE PG5 750W ATX PSU Power Supply 80+ Gold >90% Black Flat Cables Single +12V Rail Japanese >100K Hrs (NEW)
KEY FEATURE
Ultra Durable
Support PCIe Gen 5.0 graphics cards
Support Intel ATX 3.0 standard
80 PLUS Gold certified
KEY FEATURE
Ultra Durable
Support PCIe Gen 5.0 graphics cards
Support Intel ATX 3.0 standard
80 PLUS Gold certified
| Model | GP-UD750GM PG5 |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240 Vac (full range) |
| Input Current | 12-6A |
| Input Frequency | 60-50 Hz |
| Output Capacity | 750W |
| Dimension | 150 x 140 x 86mm |
| Fan Type | 120mm Hydraulic Bearing(HYB)fan |
| 80 PLUS | Gold |
| Efficiency | 90% at typical load |
| MTBF | >100,000 hours |
| Protection | OVP/OPP/SCP/UVP/OCP/OTP |
| Power Good Signal | 100-150ms |
| Hold Up Time | >16ms |
| Cable Type | Flat, All black |
| Connectors | ATX/MB 20+4 Pin x 1 : 610mm*1 |
| CPU/EPS 4+4 Pin x 2 : 600mm+200mm*1 | PCIe 16 Pin x 1: 700mm*1 |
| PCIe 6+2 Pin x 4 : 600mm+150mm*2 | SATA x 8 : |
| 600mm+150mm+150mm+150mm*2 | 4 Pin Peripheral x 3+4-Pin floppy x 1 : 500mm+120mm+120mm+150mm*1 |
Gigabyte UD750GM ICE PG5 750W ATX PSU Power Supply 80+ Gold >90% Black Flat Cables Single +12V Rail Japanese >100K Hrs (NEW)
