OPTEX S3659A JX-12W PIR 12M 85DEG PET IMMUNE CEILING INDOOR-5YRS
Optex Ceiling Mount Detector, JX12W 12M Wide Angle Ceiling Detector
Minimum order qty = 30, subject to availability.
Product to be discontinued.
The JX-12W is a general purpose ceiling mount indoor PIR that features Multidimensional Analysis logic that allows the sensor to learn from the environment and understand the ambient temperature, enabling the detector to effectively detect intruders without nuisance alarms, even when the environment temperature is close to human body temperature.
The JX-12W has 148 dense zones to cover the whole detection area. Any spot within the detection area that is more than 4(quad) zones are utilised to verify if an alarm is generated or not. This enhances the accuracy level to differentiate between human or small animals.
FEATURES
• 12m 85° wide coverage
• Pet tolerance
• Noise reduction
• Anti-insect design
• Digital Quad Zone logic
• Ceiling mount general-purpose
• Effective detection - 148 zones
• Adv Temperature Compensation Logic
| Model | JX-12W |
| Detection method | Passive infrared |
| PIR coverage | 12 m 85˚ wide / 148 zones |
| Mounting | Ceiling mount: 2.0 to 5.0m |
| Detectable speed | 0.3 to 2 m/s |
| Sensitivity | 1.6˚C at 0.6 m/s |
| Pulse Count | 2 / 4 zones |
| Power Input | 9.0 to 18.0 VDC |
| Current draw | 16mA |
| Alarm period | 3.0 ± 0.5 sec |
| Warm-up period | Approx. 60 sec(LED blinks) |
| Alarm output | N.C. 28VDC 0.2A max. |
| LED Indicator | LED blinks during warm-up period LED blinks / Alarm LED Lit |
| RF Interference | No alarm 25 V/m |
| Operating temperature | -20 to +50˚C |
| Environmental humidity | 95% max |
| Weight | 200g |
