Standard&Protocol

IEEE802.3, IEEE802.3ab

Interface

2 Gigabit Ethernet ports per mesh point
 WAN and LAN on primary mesh point
both act as LAN ports on additional mesh points

Button

1 reset button

Power

Input：100-240V—50/60Hz, 0.6A
Output：DC 12V==1A

Dimension

100 x 100 x 100mm(3.1 x 3.1 x 3.1in.)

Wireless Standards

IEEE 802.11ac/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz

Data Rate

5GHz: 867 Mbps
2.4GHz: 300 Mbps

Frequency

Simultaneous dual band 2.4GHz & 5GHz

Basic Features

SSID Broadcast
Beamforming
MU-MIMO

Wireless Security

WPA2-PSK (default)

Wireless roaming

Comply with IEEE802.11v/r

Internet Connection Type

PPPoE, Dynamic IP, Static IP, Bridge Mode

DHCP Server

DHCP Server

DHCP Client List

Virtual Server

Port Forwarding

UPnP

Firewall

Forbid UDP flood attack

Forbid TCP flood attack
Forbid ICMP flood attack

DNS

Support manually setting DNS server

VPN

IPsec pass through

PPTP pass through
L2TP pass through

Other

Parental Control

Guest Network
Firmware upgrade online
Reset to factory settings

Setup Requirements

A mobile device running Android 4.0+ or iOS 8+

Temperature

Operating Temperature: 0C ~ 40C

Storage Temperature: -40C ~ 70C.

Humidity

Operating Humidity:10% ~ 90% RH non-condensing

Storage Humidity: 5% ~ 90%RH non-condensing.

Certification

FCC, CE, RoHS, EAC, IC

Package Content

(3-pack) 3 identical mesh points
3 power adapters
Quick install guide
1 gigabit ethernet cable
