Ubiquiti NanoSwitch, N-Sw, With Four Gigabit Ethernet Ports, Outdoor, Weather-resistant Enclosure, N-sw
SKU: N-SW
Tech Specs: Click Here
Installation Guide: Click Here
Description:
The Ubiquiti NanoSwitch is an unmanaged switch with four Gigabit Ethernet ports that supports up to 4 Gbps (non‑blocking line rate). Powered by 24V PoE in port 1, it provides PoE passthrough to the remaining 3 ports. The NanoSwitch is ideal for outdoor deployment with its weather resistant form factor. It is also easy to install as it can be mounted on a pole or wall.
The NanoSwitch has four PoE ports:
(1) PoE In 24V, 2-Pair
(3) PoE Passthrough 24V, 2-Pair
Power supply not included.
Features:
•(3) GbE RJ45 ports with 24V passive PoE
•24W PoE supply
•Outdoor, weather-resistant enclosure
Specifications
N-SW
Dimensions 196.4 x 93.5 x 32.4 mm (7.73 x 3.68 x 1.28")
Weight 271 g (9.6 oz)
Enclosure Characteristics White Polycarbonate
Total Non-Blocking Line Rate 4 Gbps
Typical Power Consumption 1.5W
Passive PoE Max. Wattage per Port 24V, 2-Pair, 1A per Port (24W)
Total Passive PoE Max. Wattage 24V, 2-Pair, 1A for 3 Ports (24W)
Power Method Passive 24V, 2-Pair PoE In
Power Supply POE-24-24W PoE Adapter (Not Included)
Passive PoE Voltage Range 21.6 - 26.4V
LEDs Speed/Link/Activity (All Ports)
Networking Interfaces (4) 10/100/1000 Mbps RJ45 Ports
PoE Interfaces Passive 24V, 2-Pair PoE In
ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV
Operating Temperature -30 to 70° C (-22 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Shock and Vibration ETSI300-019-1.4 Standard
Certifications CE, FCC, IC
