10GBASE-T Connections
Support low-latency, line-rate 10G Copper “BASE-T” technology with backward compatibility to Gigabit Ethernet and Fast Ethernet. Cost-effectively migrate current network to 10G capacity by utilizing the existing Cat 6 RJ45 short connections (up to 45m) and Cat 6a / Cat 7 connections up to 100m.

10GBASE-X SFP+ ports
Providing flexibility to uplink to 10G-capable core or aggregation switches that support fiber links. Backward compatible to Gigabit fiber. Support copper or fiber modules.

Multi-Gigabit Connections
Support line-rate 2.5G/5G "NBASE-T" technology with backward compatibility to Gigabit Ethernet and Fast Ethernet. Upgrade your current network without upgrading your existing cabling, thanks to Multi-Gigabit you will be able to run 5G and 2.5G over connections up to 100m.
SOFTWARE FEATURES
Comprehensive QoS Features
Advanced controls for optimized network performance and better delivery of mission-critical traffic such as voice and video. Ingress and egress rate limiting allows for bandwidth shaping for mitigating network resources constraints or for optimizing guest access bandwidth on the network.
Port-based or 802.1p-based prioritization
Layer 3-based (DSCP) prioritization
Port-based ingress and egress rate limiting

IGMP Snooping
For improved network efficiency on delivering multicast traffic. Save cost and improve network efficiency by ensuring multicast traffic only reaches designated receivers without the need of an extra multicast router.
Loop Detection / Auto DoS Prevention
Detect accidental network loops and protect against DoS (Denial of Service) attacks.

Port-based & 802.1Q-based VLANs
Segment network into smaller groups for more secure and efficient use of network resources.
Port Trunking / Link Aggregation (LAG)
Build up bigger bandwidth to support aggregated uplink/downlink traffic.

Energy Effiecient Ethernet (IEEE 802.3az)
For maximum power savings and reduced energy costs.
Port Mirroring
For better and quicker network diagnostics and troubleshooting.

Cable Test
Easily identify bad Ethernet cables.

L2 Services - VLANs
IEEE 802.1Q VLAN tagging
Port-based VLANs (physical)
L2 Services - Availability
Broadcast, multicast, unknown unicast storm control
Static manual LAGs (port trunking)
IEEE 802.3x (full duplex and flow control)
L2 Services - Multicast Filtering
IGMP snooping (v1, v2 and v3)
Block unknown multicast
L3 Services - DHCP
DHCP client
Link Aggregation
Static manual LAGs (port trunking)
4 LAGs (XS708Ev2) or 8 LAGs (XS716E) with max 8 members in each LAG
GS110EMX, XS512EM, XS724EM supports LACP
Network Security
Broadcast, multicast, unknown unicast storm control
DoS attacks prevention
Quality of Service (QoS)
Port-based rate limiting (ingress and egress)
Port-based QoS
IEEE 802.1p COS
IPv4 DSCP
IPv4 ToS
Weighted Round Robin (WRR)
Management
Password management
Web browser-based graphical user interface (GUI) for advanced configuration and management
ProSAFE Plus Configuration Utility (PCU) for multi-switch management (requires Windows PC)
Firmware upgrade via HTTP (Web GUI) or TFTP (Plus Utility)
Config file transfers (backup, restore) using web browser-based management GUI or Plus Utility
Port mirroring; many-to-one port mirroring
Energy Efficient Ethernet (EEE) IEEE 802.3az (deactivated by default)
Short cable power reduction
Auto power-down
NETGEAR Warranty
This product is backed by a NETGEAR ProSAFE® Limited Lifetime Hardware Warranty.
Lifetime Next Business Day Hardware Replacement. Click here for coverage, availability and terms and conditions.
ProSUPPORT 24x7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts.
ProSUPPORT Lifetime 24x7 Advanced Technical Support via chat.
