Asus Prime Z890M-Plus WIFI-Csm LGA1851 Matx Motherboard, DDR5 256GB, PCIe 5.0, 3×M.2, 2.5GbE, Wi-Fi 7, USB 20Gbps Type-C Prime Z890M-PLUS Wifi-csm
SKU
421578
Brand
Warranty
Standard Manufacturer's Warranty
No Longer Available
$359.00
Buy Now And Earn 359 Reward Points!
ASUS PRIME Z890M-PLUS WIFI-CSM LGA1851 mATX Motherboard, DDR5 256GB, PCIe 5.0, 3×M.2, 2.5GbE, Wi-Fi 7, USB 20Gbps Type-C
ASUS PRIME series motherboards are expertly engineered to unleash the full potential of the latest Intel® Core™ Ultra Processors (Series 2). Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, the PRIME Z890M-PLUS WIFI-CSM motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.
*Graphics
ASUS PRIME series motherboards are expertly engineered to unleash the full potential of the latest Intel® Core™ Ultra Processors (Series 2). Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, the PRIME Z890M-PLUS WIFI-CSM motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.
*Graphics
| Model | PRIME Z890M-PLUS WIFI-CSM |
| CPU | Supports Intel® Core™ Ultra Processors(Series 2), LGA1851* |
| Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** | * Refer to https://www.asus.com/support/download-center/ for CPU support list. |
| Chipset | Intel® Z890 Chipset |
| Memory | 4 x DIMM slots, max. 256GB, DDR5 |
| Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)* | Dual channel memory architecture |
| DIMM Fit | Supports Intel® Extreme Memory Profile (XMP) |
| ASUS Enhanced Memory Profile III(AEMPIII) | Graphics |
| 1 x DisplayPort** | 1 x HDMI™ port*** |
| 1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output**** | *Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. |
| **Supports max. 4K@60Hz as specified in DisplayPort 1.4. | ***Supports 4K@60Hz as specified in HDMI 2.1. |
| ****Supports max. 4K@120Hz as specified in DisplayPort 1.4. | ***** VGA resolution support depends on processors' or graphic cards' resolution. |
| Ethernet | 1 x Realtek 2.5Gb Ethernet |
| ASUS LANGuard | Special Features |
| ASUS 5X PROTECTION III | ASUS 5X PROTECTION III |
| - DIGI+ VRM (- Digital power design with DrMOS) | - LANGuard |
| - Overvoltage Protection | - SafeSlot |
| - Stainless-Steel Back I/O | ASUS Q-Design |
| - Q-Antenna | - Q-Dashboard |
| - Q-DIMM | - Q-LED Core |
| - Q-Slot | ASUS Thermal Solution |
| - VRM heatsink design | ASUS EZ DIY |
| - BIOS FlashBack™ button | - BIOS FlashBack™ LED |
| - ProCool | - Pre-mounted I/O shield |
| Aura Sync | - Aura RGB header |
| - Addressable Gen 2 headers | BIOS |
| 256 (128+128) Mb Flash ROM, UEFI AMI BIOS | Operating System |
| Windows 11 (22H2 & later) | Form Factor |
| mATX Form Factor | 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm) |
ASUS PRIME Z890M-PLUS WIFI-CSM LGA1851 mATX Motherboard, DDR5 256GB, PCIe 5.0, 3×M.2, 2.5GbE, Wi-Fi 7, USB 20Gbps Type-C
