Axis Provides power over Ethernet to Axis network video products with built-in PoE support. AXIS
QUICK OVERVIEW
Easier and faster installations Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for supplying power to network video products without the need to install power outlets and electrical cabling. No need for power outlets With the use of Axis PoE products, Axis network cameras and video encoders can receive both data and power over a single Ethernet cable. Network video products can thus be installed in areas where traditional power cabling and outlets are unavailable or difficult to install.
General Information | |
---|---|
Brand Name: | AXIS |
Manufacturer Part Number: | 5026-206 |
Manufacturer Website Address: | http://www.axis.com |
Manufacturer: | Axis Communications |
Marketing Information: | Easier and faster installations Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for supplying power to network video products without the need to install power outlets and electrical cabling. No need for power outletsWith the use of Axis PoE products, Axis network cameras and video encoders can receive both data and power over a single Ethernet cable. Network video products can thus be installed in areas where traditional power cabling and outlets are unavailable or difficult to install. |
Product Model: | T8120 |
Product Name: | T8120 Midspan 15 W 1-port |
Product Type: | PoE Injector |
Interfaces/Ports | |
---|---|
Input Ports: | 1 10/100Base-TX |
Output Ports: | 1 10/100Base-TX |
Physical Characteristics | |
---|---|
Depth: | 139.7 mm |
Height: | 33 mm |
Mount Type: | Wall/Shelf-mountable |
Weight (Approximate): | 453.6 g |
Width: | 53.3 mm |
Power Description | |
---|---|
Input Voltage: | 120 V AC |
? | 230 V AC |
Maximum Frequency: | 63 Hz |
Maximum Input Current: | 500 mA |
Maximum Output Power: | 15 W |
Maximum Output Voltage: | 12 V DC |
Minimum Frequency: | 47 Hz |
Warranty | |
---|---|
Limited Warranty: | 3 Year |
