DeepCool PS750G WH

Technical Spec

Model PS750G WH
Model No PS750G-FE
Total Output 750W
Type SFX12V V4.1 & ATX12V V3.1
Product Dimensions 125×100×63.5mm (W x L x H)
Efficiency certification Cybenetics Platinum /PPLP Gold
Fan Size 92x92x20mm (W x L x H)
Fan Bearing FDB (Fluid Dynamic Bearing)
Topology Active PFC + Half Bridge SRC LLC + DC to DC
Capacitors Full Japanese Electrolytic Capacitors
Power Good Signal 100-150ms
Hold Up Time ≥16ms(80% Load)
Efficiency ≥90% Under Typical Load(50% Loading)
Protection OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature 0~40°C
Regulatory CE/CCC/TUV-RH/KC/RCM/CAN ICES(B)/NMB(B)/EAC
Erp Regulation ErP 2014
Environment Protection WEEE/中国 RoHS/Triman/EAC RoHS
MTBF 100,000 Hours
Warranty 5Years
