PATRIOT S4716A POWER SUPPLY ADJ 27.6V 24V-4A 2YRS
SKU
401942
Brand
MPN
ACPS24
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$209.00
Buy Now And Earn 209 Reward Points!
Looking for 24v DC power supply? Look no further, OPS-24V-8A, adjustable 27.6VDC 4A Power Supply.
FEATURES:
- Extremely compact and efficient (small footprint)
-1.2A charger able to charge up to 8 x 12V 7AH battery
- Mains fail relay contact and LED
- Low battery relay contact and LED-
- Reverse polarity protection on battery terminal
- Australian 10A plug on input
- Parallel configuration to increase current output possible
| Input Voltage | 85 ~ 264VAC |
| Output Voltage Range (Adjustable) | 22.4 ~ 27.6VDC (Preset @ 12VDC) |
| Output Voltage Tolerance | ± 1% |
| Max Power Output Current | 4.25A |
| Power Supply Protection | Short Circuit, Overload and Over Voltage |
| Australian Regulatory Compliance Mark (RCM) | N12754 |
| Dimensions / Weight | 260x130x60mm / 1.2Kg |
| Contacts | Mains Failure & Low Battery |
