INOVONICS S4748 DUAL INPUT UNI TRANS SUP 3MIN 3YR
SKU
403457
Brand
MPN
S4748
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$128.00
Buy Now And Earn 128 Reward Points!
Dual Input Universal
The Inovonics EN1212 dual input universal transmitter is designed for use with any standard contact or sensor that provides a contact closure. The primary alarm input is selectable – normally open or closed – and the secondary alarm input is set to normally closed only.
Key Features
- Supports dual inputs
- Can be used with almost any standard NO/NC contact
- Fully supervised
- Includes case tamper protection
| Dimensions: | 8.9 x 4.3 x 2.3 cm |
| Weight: | 54g |
| Typical battery life: | 3-5 years |
| Internal battery type: | Panasonic CR123A |
| External contacts: | Input one can be normally open or normally closed; input two is always normally closed" |
| External contact cabling requirements: | 0.5mm² to 2.5mm², unshielded |
| Distance, external contact to trasmitter: | 3m maximum |
| Temperature: | -20 to 60°C |
| Humidity: | Up to 90% (non-condensing) |
| Market: | North America, Australia, New Zealand |
| EchoStream® frequency: | 902-928 MHz, frequency hopping spread spectrum |
| Check-in time frequency: | 3 Minutes |
| Regulatory compliance: | EN1212: FCC, ISED, RCM, RoHS; EN1212-60: FCC, RoHS, UL 25601 |
