DESCRIPTION

Output
• Output power capacity: 2.1 KWatts / 3.0 kVA
• Max Configurable Power (Watts): 2.1 KWatts / 3.0 kVA
• Nominal Output Voltage: 230V
• Output Voltage Distortion: Less than 5% at full load
• Output Frequency (sync to mains): 50 Hz
• Topology: Line Interactive
• Waveform type: Sine wave
• Output Connections: ◦ (8) IEC 320 C13 (Battery Backup)
◦ (1) IEC 320 C19 (Battery Backup)


Input
• Nominal Input Voltage: 230V
• Input frequency: 47 - 63 Hz
• Input Connections: IEC-320 C20
• Input voltage range for main operations: 180 - 287 V
• Input voltage adjustable range for mains operation: 170 - 300 V
• Other Input Voltages: 220, 240

Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte: leakproof
• Typical recharge time:3 hour(s)
• Replacement Battery: APCRBC150
• RBC Quantity: 1
• Battery Volt-Amp-Hour Capacity: 552
• Runtime: View Runtime Graph View Runtime Chart

Communications & Management
• Interface Port(s): USB
• Control panel: Multi-function LCD status and control console
• Audible Alarm: Alarm when on battery: distinctive low battery alarm: configurable delays
• Emergency Power Off (EPO): --

Surge Protection and Filtering
• Surge energy rating: 300 Joules
• Filtering: Full time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449

Physical
• Maximum Height: 435 mm, 43.5 cm
• Maximum Width: 197 mm, 19.7 cm
• Maximum Depth: 544 mm, 54.4 cm
• Net Weight: 43.0 kg
• Shipping weight: 51.0 kg
• Shipping Height: 762 mm, 76.2 cm
• Shipping Width: 381 mm, 38.1 cm
• Shipping Depth: 699 mm, 69.9 cm
• Color: Black

Environmental
• Operating Environment: 0 - 40 °C
• Operating Relative Humidity: 0 - 95 %
• Operating Elevation: 0-3000 meters
• Storage Temperature: -15 - 45 °C
• Storage Relative Humidity: 0 - 95 %
• Storage Elevation: 0-15000 meters
• Audible noise at 1 meter from surface of unit: 45.0 dBA
• Online therm
