main product photo

Synology E10g18-t2 10gbe Single Ethernet Adapter Card With Rj-45 Connectors. E10g18-t2

SKU
270885
Brand
Synology
Manufacturer Link
Manufacturer Product Link
Warranty
Standard Manufacturer's Warranty

No Longer Available

$0.00
Buy Now And Earn 0 Reward Points!
Add to Compare

Achieve outstanding network performance with minimal effort

Enjoy a smooth migration to high-speed 10Gbps Ethernet. E10G18-T2 delivers superior transmission performance with the capability to offload packet processing and free up CPU resources for more tasks. It supports IEEE 802.3an/ab (10GBASE-T/1000BASE-T) and 802.3x with dual RJ-45 connectors, providing a total data rate of 20Gbps using standard CAT6 or better UTP cabling connections. Features such as Link Aggregation, Jumbo Frame, TSO, and TCP/UDP/IP Checksum offloading satisfy most workloads requiring high performance, making E10G18-T2 an ideal and economical solution for 10Gbps networking adoption.

5 year warranty

Built to handle intensive workloads, Synology network add-in-cards are backed by Synology's 5 year limited warranty.

General Specifications
Standards
  • IEEE 802.3an 10Gbps Ethernet
  • IEEE 802.3ab Gigabit Ethernet
  • IEEE 802.3ad Link Aggregation
  • IEEE 802.3x Flow Control
Data Transfer Rates 10 Gbps
Network Operation Mode Full Duplex
Supported Features
  • 9 KB Jumbo Frame
  • TCP/UDP/IP Checksum Offloading
  • TCP Segmentation Offload (TSO)
Applied Models
  • FS3017
  • FS2017
  • FS1018
  • RS18017xs+
  • RS18016xs+
  • RS10613xs+
  • RS4017xs+
  • RS3618xs
  • RS3617xs+
  • RS3617RPxs
  • RS3617xs
  • RS3614xs+
  • RS3614(RP)xs
  • RS3413xs+
  • RS3412(RP)xs
  • RS3411(RP)xs
  • RS2818RP+
  • RS2418(RP)+
  • RS1619xs+
  • RS1219+
  • RS818(RP)+
  • RC18015xs+
  • DS3617xs
  • DS3615xs
  • DS3612xs
  • DS3611xs
  • DS3018xs
  • DS1819+
  • DS1817+
  • DS1618+
  • DS1517+
Note DSM version requirement: 6.2.1-23824 or later version
Hardware Specifications
PCIe Interface PCIe 3.0 x8
Bracket Height Low Profile and Full Height
Size (Height x Width x Depth) 170.6 mm x 68.9 mm x 13.6 mm
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Warranty 5 Years
Synology E10G18-T2 equipped with an RJ-45 connector and supports IEEE 802.3an/bz (10GBase-T/NBase-T) and 802.3x2,E10G18-T2 helps you smoothly migrate to a 10Gbe networking environment with your existing infrastructure. Supporting backward compatibility and auto-negotiation between 10Gbps, 5Gbps , 2.5Gbps , 1Gbps and 100Mbps data rate, E10G18-T2 is an economic solution to overcome the data transmission bottlleneck for small businesses and home users.Specs: *IEEE 802.1Q VLAN Tagging*IEEE 802.3x Flow Control*IEEE 802.3ae 10Gbps Data Transfer Rates: 10GbpsNetwork Operation Mode: Full Duplex (20 Gbps)Supported Features :*9KB Jumbo Frame*Simple Network Management Protocol (SNMP) Agent*IEEE 802.3ad Link Aggregation Support*TCP/UDP/IP Checksum OffloadingSupported OS:Synology Diskstation Manager (DSM) 5.1 and onward.Supported Models :FS3017FS2017FS1018RS18017xs+RS18016xs+RC18015xs+RS10613xs+RS4017xs+RS3617xs+RS3614xs+RS3413xs+RS3618xsRS3617RPxsRS3617xsRS3614(RP)xsRS3412(RP)xsRS3411(RP)xsDS3617xsDS3615xsDS3612xsDS3611xsDS3018xsRS2818RP+RS2418(RP)+RS1219+RS818(RP)+DS1817+DS1618+DS1517+
