Synology Expansion Unit Rx1217sas 12-bay 3.5" Diskless Nas (2u Rack) (smb/ent) For Scalable Nas

SKU
234154
Brand
Synology
Manufacturer Link
MPN
RX1217sas
Manufacturer Product Link
Warranty
Standard Manufacturer's Warranty
Availability
Preorder (Contact Us)
Freight Estimate
$5,717.00
Buy Now And Earn 5717 Reward Points!

QUICK OVERVIEW

Models FS3017 / RS18017xs+ Model backed with SRS! RX1217sas
Add to Compare

12-bay 3.5”/2.5” SAS/SATA expansion

Easily add 12 additional drive bays to Synology FlashStation or RackStation1. Supporting both 2.5” and 3.5” SAS/SATA drives, the RX1217sas is a flexible solution supporting on-the-fly volume expansion or serving as a local backup destination.


　

Maximum reliability design

Dual power supplies ensure continuous service uptime. Easily replace defective drives with the hot swappable drive trays. Experience fast and secure rack cabinet installation with the optional sliding rail kit RKS1317.


　
　

5 year warranty

Synology's 5-year limited warranty provides hardware replacement and technical support via email and telephone services, maximizing your enterprises' return on investment.


　

Synology Replacement Service (SRS)

SRS provides free shipment of replacement units as early as the next business day in selected regions2.

Hardware Specifications
Applied Models
  • FS3017*
  • RS18017xs+
Note Connecting to a Synology FlashStation FS3017 requires the optional FS3017 Expansion Card (FXC17) to be installed on the host device. FS3017 Expansion Card is sold separately.
Storage
Drive Bay(s) 12
Compatible Drive Type* (See all supported drives)
  • 3.5" SAS HDD
  • 2.5" SAS HDD
  • 2.5" SAS SSD
  • 3.5" SATA HDD
  • 2.5" SATA SSD
Maximum Internal Raw Capacity 120 TB (10 TB HDD x 12) (Capacity may vary by RAID types)
Hot Swappable Drive
RAID Management through Synology DSM
External Ports
SAS IN-port 1
SAS OUT-port 1
Appearance
Size (Height x Width x Depth) 88 mm x 482 mm x 724 mm
　
Weight 18 kg
　
Power
Power Supply Unit / Adapter 2 x 500W
　
AC Input Power Voltage 100V to 240V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 132.7 W (Access)
89.3 W (HDD Hibernation)
　
British Thermal Unit 452.79 BTU/hr (Access)
304.7 BTU/hr (HDD Hibernation)
　
Redundant Power Supply (for RP model)
Temperature
Operating Temperature 5°C to 35°C (40°F to 95°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH
Others
System Fan 60 mm x 60 mm x 4 pcs
Easy Replacement System Fan
Noise Level* 60.9 dB(A)
　
Certification
  • FCC Class A
  • CE Class A
  • BSMI Class A
Warranty 5 Years
Environment & Packaging
Environment RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Cord X 2
  • Expansion Cable: MiniSAS-HD X 1
  • Quick Installation Guide X 1
Optional Accessories Synology RKS1317 - Rail Kit Sliding
Synology RX1217sas delivers an effortless solution for volume expansion and data backup for Synology FlashStation/RackStation by adding 12 SAS/SATA drive bays on-the-fly. Synology RX1217sas is backed withSynology's 5-year limited warranty. Connecting to a Synology FlashStation FS3017 requires the optional FS3017 Expansion Card FXC2017 to be installed on the host device.
⚫Model backed with Synology Replacement Service (SRS) - Conditions apply. Refer to the Synology Website
⚫Plug-n-use design for seamless storage space upgrade
⚫Online volume expansion on the fly
⚫Redundant power supplies ensure service uptime
⚫Fast rack fixing lock support with Synology RKS1317
⚫Managed by Synology DiskStation Manager (DSM)
⚫Size (HxWxD) - 88 x 430.5 x 692 mm / 88 x 482 x 724 mm (with server ears) / 2RU
