HARDWARE FEATURES

• Interface
  • 3 RJ45 LAN Ports
  • 1 RJ45 LAN/WAN Port
  • 1 RJ11 Port
  • 1 USB 2.0 Port
• Button
  • WPS Button
  • Wireless On/Off Button
  • Power On/Off Button
  • Reset Button
• Power Supply: 12V/1.5A
  • IEEE Standards
  • IEEE 802.3
  • IEEE 802.3u
  • 802.3ab
• VDSL2 Standards
  • ITU G.993.2, Up to 17a prole (POTS)
  • ITU-T G.993.5 (G.vector)
  • ITU-T G.998.4 (G.INP)
• ADSL Standards
  • Full-rate ANSI T1.413 Issue 2,
  • ITU-T G.992.1(G.DMT),
  • ITU-T G.992.2(G.Lite),
  • ITU-T G.994.1 (G.hs),
  • ITU-T G.995.1
• ADSL2 Standards
  • ITU-T G.992.3 (G.DMT.bis),
  • ITU-T G.992.4 (G.lite.bis)
• ADSL2+ Standards
  • ITU-T G.992.5
• Dimensions (W x D x H): 243.5×167.5×32.7mm
• Antenna Type: 3 xed external antennas

WIRELESS FEATURES

• Wireless Standards
  • IEEE 802.11a/n/ac 5GHz,
  • IEEE 802.11b/g/n 2.4GHz
• Wireless Speeds
  • 867Mbps at 5GHz
  • 300Mbps at 2.4GHz
• Transmit Power
  • 2.4GHz <20dBm(EIRP)
  • 5GHz <23dBm(EIRP)
• Wireless Functions
  • Enable/Disable Wireless Radio, WDS Bridge, WMM,
  • Wireless Statistics
• Wireless Security
  • 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
  • encryptions, Wireless MAC Filtering
• Wireless Schedule
  • Support 2.4GHz and 5GHz Wireless Schedule

SOFTWARE FEATURES

• Quality of Service:
  • ATM QoS, Bandwidth Control
• Security:
  • NAT Firewall, Access Control, IP and MAC Address Binding
• Operating Modes:
  • VDSL/ADSL Modem Router, Wireless Router,3G/4G Router
• Management
  • Web Based Conguration(HTTP), Remote management,
  • command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware
  • Upgrade, Diagnostic Tools
• DHCP:
  • Server, Client, DHCP Client List, Address Reservation, DHCP Relay
• Port Forwarding:
  • Virtual Server, Port Triggering, DMZ, ALG, UPnP
• Dynamic DNS:
  • DynDns, NO-IP
• VPN Pass-Through:
  • PPTP, L2TP, IPSec Passthrough
• Protocols:
  • Supports IPv4 and IPv6
• ATM/PPP Protocols
  • ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),
  • PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MERIPoE (RFC 1483
  • Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
• Advanced Functions
  • Parental Control, Network Address Translation(NAT),
  • Port Mapping(Grouping), Static Routing, RIP v1/v2(optional), DNS Relay,
  • DDNS, IGMP V1/V2/V3
• USB Sharing
  • Support Samba(Storage)/FTP Server/Media Server/Printer
  • Server, 3G/4G Modem
• Guest Network
  • 2.4GHz guest network, 5GHz guest network
• IPSec VPN
  • Supports up to 10 IPSec VPN tunnels
• Beamforming: 5GHz

OTHERS

• Certification: CE, RoHS
• Package Contents
  • AC1200 Wireless VDSL/ADSL Modem Router Archer VR400
  • External Splitter
  • RJ11 DSL Cable
  • RJ45 Ethernet Cable
  • Power Adapter
  • Quick Installation Guide
• System Requirements
  • Microsoft Windows XP/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
  • Internet Explorer, Firefox, Chrome, Safari or other Java-enabled browser
  • Subscription with an Internet Service Provider (for Internet access)
• Environment
  • Operating Temperature: 0?~40? (32? ~104?)
  • Storage Temperature: -40?~70? (-40? ~158?)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing

TP-Link Archer VR400 AC1200 Wireless VDSL/ADSL Modem Router 1.2Gbps 867Mbps @ 5GHz 300Mbps @ 2.4GHz 3xLAN 1xWAN 1xUSB 1xRJ11 3xAntenna

Speedy Wi-Fi – Superb wireless experience with 300Mbps (2.4GHz) + 867Mbps (5GHz) dual band Wi-Fi connections
Superior Range – Three fixed antennas provide stable wireless connections and optimal coverage
Versatile Connectivity – Fully compatible with the VDSL2/ADSL2+/ADSL2/ADSL standards, as well as fiber, cable and 3G/4G Internet services
Beamforming Technology – Improves wireless range and performance at 5GHz band
USB Port – Supports storage and print service sharing, FTP and media servers as well as 3G/4G dongle
Tether App – TP-LINK Tether provides the easiest way to access and manage the router on your iOS and Android devices

HARDWARE FEATURES
Interface 3 10/100 RJ45 LAN Ports
1 10/100/1000 RJ45 LAN/WAN Port
1 RJ11 Port
1 USB 2.0 Port
Button WPS Button
Wireless On/Off Button
Power On/Off Button
Reset Button
Power Supply 12V/1.5A
IEEE Standards IEEE 802.3
IEEE 802.3u
802.3ab
VDSL2 Standards ITU G.993.2, Up to 17a prole (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP)
ADSL Standards Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
ITU-T G.994.1 (G.hs),
ITU-T G.995.1
ADSL2 Standards ITU-T G.992.3 (G.DMT.bis),
ITU-T G.992.4 (G.lite.bis)
ADSL2+ Standards ITU-T G.992.5
Dimensions ( W x D x H ) 243.5×167.5×32.7mm
Antenna Type 3 fixed external antennas
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n/ac 5GHz,
IEEE 802.11b/g/n 2.4GHz
Wireless Speeds 867Mbps at 5GHz
300Mbps at 2.4GHz
Transmit Power 2.4GHz <20dBm(EIRP)
5GHz <23dBm(EIRP)
Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions, Wireless MAC Filtering
Wireless Schedule Support 2.4GHz and 5GHz Wireless Schedule
