The TL-SG1024 is specially designed for Ethernet (10Mbps), Fast Ethernet (100Mbps) and Gigabit Ethernet (1000Mbps) with seamless link. Each port supports up to 2000Mbps throughput in full duplex mode. It is the perfect choice to improve the performance of Offices and workgroup networks.

Fully compliant with IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX) and IEEE 802.3ab (1000BASE-T)
24 10/100/1000Mbps Auto-negotiation Ethernet Ports
All ports support Full/half duplex transfer mode for 10Mbps/100Mbps and Full duplex transfer mode for 1000Mbps
Supports Auto-MDI/MDIX function
Supports IEEE 802.3X flow control for full-duplex mode and back pressure flow control for half-duplex mode
Store and forward Switching scheme

Standard
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3ab
Port: 24 10/100/1000M Auto-Negotiation RJ45 ports supporting Auto MDI/MDIX
Network Media:
- 10Base-T: Cat. 3 or above UTP
- 100Base-TX: Cat.5 UTP
- 1000Base-T: Cat.5 UTP
Filter and transmission rate
- 10Mbps: 14880pps
- 100Mbps: 148800pps
- 1000Mbps: 1488000pps
LED Indicator
- Each port: Link/Act, 10M/100M, 1000M
- Others: Power
Dimension (L x W x H): 17.3 x 7.1 x 1.7 in.(440 x 180 x 44 mm)
Environment
- Operation Temperature: 0C-40C
- Store Temperature: -40C-70C
- Operation Humidity: 10%-90% RH Non-condensing
- Store Humidity: 5%-90% RH Non-condensing
Power: Input: 100-240VAC, 50/60Hz
