Tp-link Tl-ant2414a 2.4ghz 14dbi Outdoor Yagi-directional Antenna

SKU
12531
Brand
Tp-link
Manufacturer Link
Manufacturer Product Link
Warranty
1 Year Manufacturer's return to base

No Longer Available

$0.00
Buy Now And Earn 0 Reward Points!
Add to Compare

2.4GHz 14dBi Outdoor Directional AntennaTL-ANT2414A

  • 14dBi directional operation provides extended point to point connection or indoor and outdoor area coverage
  • Features 100cm CFD-200 low loss cable for flexible deployment
  • RP-SMA Female connector, works with most of access points / wireless routers
  • Provides easy installation mounting kits

What This Product Does

Directional Antenna TL-ANT2414A operates in the 2.4GHz band and provides 14dBi directional operation, which largely extends the wireless range and delivers much better wireless performance. The antenna offers the RP-SMA female connector guaranteeing wider compatibility with most of the wireless equipments.


Enjoy the benefits of wireless connectivity at greater distances and throughput throughout your indoor wireless zone. No configuration or installation software required .

Easy To Use

Installation of the TL-ANT2414A is simple and straight forward. It is compatible with most wireless devices (Access Points, Routers, Bridges and Network Adapters) on the market with removable external antennas.
ANTENNA
Frequency 2.4GHz
Gain 14dBi
VSWR(MAX.) 1.5:1
HPOL Beamwidth 30
VPOL Beamwidth 30
Polarization Linear; Vertical
Type Directional
Connector Type RP-SMA Female
Extended Cable/Length CFD-200 ; 100cm
Mounting Pole Mount/Wall Mount
Application Outdoor
Approximate Range at 1/11/54Mbps 5km/3km/440m
Optional Accessory TL-ANT24EC3S TL-ANT24EC5S
Package Contents 14dBi Panel Directional indoor Antenna
Installation mounting kits
User Guide

Details:

Directional Antenna TL-ANT2414A operates in the 2.4GHz band and provides 14dBi directional operation, which largely extends the wireless range and delivers much better wireless performance. The antenna offers the RP-SMA female connector guaranteeing wider compatibility with most of the wireless equipments

Enjoy the benefits of wireless connectivity at greater distances and throughput throughout your indoor wireless zone. No configuration or installation software required

Easy To Use

Installation of the TL-ANT2414A is simple and straight forward. It is compatible with most wireless devices (Access Points, Routers, Bridges and Network Adapters) on the market with removable external antennas.

Specifications:

  • Frequency: 2.4GHz
  • Gain: 14dBi
  • VSWR (MAX.): 1.5:1
  • HPBW/H: 30°
  • HPBW/V: 30°
  • Polarization: Linear; Vertical
  • Type: Directional
  • Connector Type: RP-SMA Female
  • Extended Cable/Length: CFD-200 ; 100cm
  • Mounting: Pole Mount/Wall Mount
  • Application: Outdoor
  • Approximate Range at 1/11/54Mbps: 5km/3km/440m
  • Optional Accessory: TL-ANT24EC3S, TL-ANT24EC5S
  • Package Contents:
    • 14dBi Panel Directional indoor Antenna
    • Installation mounting kits
    • User Guide
