No Longer Available
| HARDWARE FEATURES | |
|---|---|
| Interface | 3 10/100Mbps RJ45 LAN Ports, 1 10/100Mbps RJ45 LAN/WAN Port, 1 RJ11 DSL Port, 2 FXS Port, 1 USB Port |
| Button | Power On/Off Button, WPS On/Off Button, Wireless On/Off Button, RESET Button |
| External Power Supply | 12V/1.5A |
| Dimensions ( W x D x H ) | 6.9 x 2.4 x 5.1 in. (174 x 60 x 130 mm) |
| Antenna | 2.4G 2 Internal Antennas |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11b/g/n 2.4GHz |
| Frequency | 2.4GHz |
| Signal Rate | 300Mbps at 2.4GHz |
| Transmit Power | <20dBm(EIRP) |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, Wireless MAC Filtering |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | WMM, Bandwidth Control |
| Security | NAT Firewall, SPI Firewall, MAC / IP / URL Filtering |
| Management | Web Based Con_guration(HTTP), Remote management, Telnet management, Command Line Interface, SSL for TR-069, SNMP v1/2c Web Based Firmware Upgrade, CWMP(TR-069), Diagnostic Tools |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP Relay |
| Port Forwarding | Virtual Server, Port Triggering, DMZ, UPnP, Manage Control |
| VPN Pass-Through | PPTP, L2TP, IPSec Pass-through |
| Protocols | Supports IPv4 and IPv6 |
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), PVC - Up to 8 PVCs |
| VOIP Features | Two RJ-11 FXS ports for connecting to regular telephones Call hold, Call transfer, Call internal transfer, Call forward, Warm call, Do not disturb, Anonymous call, Call restriction, Speed dial, etc. Caller ID, 3-party conference, SIP account – up to 8 accounts |
| System Function | Parental Control, Traf_c Shaping(ATM QoS) UBR, CBR, VBR-rt, VBR-nrt, Dynamic Host Conguration Protocol (DHCP), DHCP relay, Network Address Translation (NAT), PVC/Ethernet Port Grouping Static Routing, RIP v1/v2 (optional), DNS Relay, DDNS |
| OTHERS | |
|---|---|
| Certification | CE, RCM |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10,
MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
