Ubiquiti Cat5e Carrier Outdoor Cable, 305m, Carrier-Class Shielded Cable W/ Integrated Esd Drain Wire, Replaces Tc-Carrier UISP-Cable-Carrier
SKU
367625
Brand
MPN
UISP-Cable-Carrier
Warranty
Standard Manufacturer's Warranty
$348.00
Buy Now And Earn 348 Reward Points!
Ubiquiti UISP Cable Carrier
SKU: UISP-Cable-Carrier
Tech Specs: Click Here
Description: The UISP-Cable-Carrier is a Industrial-grade Ethernet cable that protects your network from elemental and electrostatic damage, its a Category 5e cable, that delivers multilayered elemental protection with a primary braid shield and a weatherproof jacket that prevents damage from rain, snow, and other harsh climatic conditions. The cable is also equipped with a drain wire and internal foil shielding to protect it from electrostatic discharge (ESD), and its anti-crosstalk divider preserves signal integrity, allowing the cable to maintain Gigabit Ethernet link rates even when electromagnetic interference is present.
Features:
•1,000 ft (305 m) Category 5e cable
•24 AWG solid copper conductor pairings
•Insulated, weatherproof cable jacket
•Internal braid and foil shielding
•Drain wire that protects against ESD damage
•Anti-crosstalk divider
SKU: UISP-Cable-Carrier
Tech Specs: Click Here
Description: The UISP-Cable-Carrier is a Industrial-grade Ethernet cable that protects your network from elemental and electrostatic damage, its a Category 5e cable, that delivers multilayered elemental protection with a primary braid shield and a weatherproof jacket that prevents damage from rain, snow, and other harsh climatic conditions. The cable is also equipped with a drain wire and internal foil shielding to protect it from electrostatic discharge (ESD), and its anti-crosstalk divider preserves signal integrity, allowing the cable to maintain Gigabit Ethernet link rates even when electromagnetic interference is present.
Features:
•1,000 ft (305 m) Category 5e cable
•24 AWG solid copper conductor pairings
•Insulated, weatherproof cable jacket
•Internal braid and foil shielding
•Drain wire that protects against ESD damage
•Anti-crosstalk divider
| Box Dimensions | 330 x 425 x 340 mm (13 x 16.7 x 13.4") |
| Box Weight | 16 kg (35.3 lb) |
| Cable Lenght | 305m (1000ft) |
| Cable Color | Black |
| Cable Type | CAT5e, Shielded |
| Ethernet Support | Up to 1 Gbps |
| Conductor Wire Gauge | 24 AWG |
| Conductor | Solid Bare Copper |
| Conductor Diameter | 0.500 ± 0.005 mm |
| Insulation Type | Solid Polyethylene |
| Insulation Thickness |
Avg. 0.295 mm Min. 0.29 mm |
| Insulation Diameter | 1.16 ± 0.02 mm |
| Separation (Polyester Wrapping) | Thick: 0.025 mm, Extent: 20 mm |
| Anti-Crosstalk Divider | LDPE: 4.2*0.3 mm |
| Cable Shield (Aluminum Foil) | Thick: 0.060 mm, Extent: 20 mm |
| ESD Drain Wire | 0.4 TC |
| Rip Cord | Yes |
| Secondary Cable Shield (Braid) | 16*8*0.16AA Density: 95% |
| Jacket Material | Polyethylene |
| Jacket Thickness |
Avg. 0.52 mm Min. 0.46 mm |
| Jacket Outer Diameter | 6.8 ± 0.30 mm |
| Jacket Color | Black |
| Storage Temperature | -30 to 75° C (-22 to 167° F) |
| Installation Temperature | -20 to 60° C (-4 to 140° F) |
| Operation Temperature | -40 to 80° C (-40 to 176° F) |
| Standards |
ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2) |
