Ubiquiti Uisp Cable Pro, Industrial-grade Outdoor Cable, 305m, Carrier-Class Shielded, Integrated Esd Drain Wire, Replaces Tc-Pro UISP-Cable-Pro
SKU
367626
Brand
MPN
UISP-Cable-Pro
Warranty
Standard Manufacturer's Warranty
$285.00
Buy Now And Earn 285 Reward Points!
Ubiquiti UISP Cable Pro
SKU: UISP-Cable-Pro
Description:
Industrial-grade Ethernet cable that protects your network from elemental and electrostatic damage. The UISP-Cable-Pro is a Category 5e cable with a highly insulating, weatherproof jacket that prevents damage from rain, snow, and other extreme climatic conditions. The cable is also fortified with internal foil shielding and a drain wire that collectively shield it from electrostatic discharge (ESD) and allow it to maintain Gigabit Ethernet link rates even when electromagnetic interference is present.
Tech Specs: Click Here
Features:
•Category 5e cable
•Insulated, weatherproof cable jacket
•Internal foil shielding and drain wire for increased ESD damage protection
•Cable length 305 m
•24 AWG solid copper conductor pairings
SKU: UISP-Cable-Pro
Description:
Industrial-grade Ethernet cable that protects your network from elemental and electrostatic damage. The UISP-Cable-Pro is a Category 5e cable with a highly insulating, weatherproof jacket that prevents damage from rain, snow, and other extreme climatic conditions. The cable is also fortified with internal foil shielding and a drain wire that collectively shield it from electrostatic discharge (ESD) and allow it to maintain Gigabit Ethernet link rates even when electromagnetic interference is present.
Tech Specs: Click Here
Features:
•Category 5e cable
•Insulated, weatherproof cable jacket
•Internal foil shielding and drain wire for increased ESD damage protection
•Cable length 305 m
•24 AWG solid copper conductor pairings
| Box Dimensions | 330 x 330 x 340 mm (13 x 13 x 13.4") |
| Box Weight | 12 kg (26.5 lb) |
| Cable Length | 305 m (1000 ft) |
| Cable Color | Black |
| Cable Type | CAT5e, Shielded |
| Ethernet Support | Up to 1 Gbps |
| Conductor Wire Gauge | 24 AWG |
| Conductor | Solid Bare Copper |
| Conductor Diameter | 0.500 ± 0.005 mm |
| Insulation Type | Solid Polyethylene |
| Insulation Thickness |
Avg. 0.26 mm Min. 0.25 mm |
| Insulation Diameter | 1.04 ± 0.03 mm |
| Separation (Polyester Wrapping) | Thick: 0.025 mm, Extent: 20 mm |
| Anti-Crosstalk Divider | None |
| Cable Shield (Aluminum Foil) | Thick: 0.060 mm, Extent: 18 mm |
| ESD Drain Wire | 0.4 CCS |
| Rip Cord | Yes |
| Jacket Material | Polyethylene |
| Jacket Thickness |
Avg. 0.50 mm Min. 0.46 mm |
| Jacket Outer Diameter | 6.0 ± 0.30 mm |
| Jacket Color | Black |
| Storage Temperature | -30 to 75° C (-22 to 167° F) |
| Installation Temperature | -20 to 60° C (-4 to 140° F) |
| Operation Temperature | -40 to 80° C (-40 to 176° F) |
| Standards |
ANSI/TIA-568-C.2 (2009) ISO/IEC 11801 (Edition 2.2) |
