HARDWARE FEATURES
Interface	Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *)
Physical Security Lock	Yes
Button	Reset
Power Supply	802.3af/at PoE 24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
Power Consumption	EU: 10.5 W US: 12.6W
Dimensions ( W x D x H )	8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)
Dimensions	8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm)
Antenna Type	3 Internal Omni * 2.4GHz: 4dBi 5GHz: 5dBi
Mounting	Ceiling /Wall Mounting (Kits included)
Hardware Watch Dog	Yes

WIRELESS FEATURES
Wireless Standards	IEEE 802.11ac/n/g/b/a
Frequency	2.4GHz and 5GHz
Signal Rate	5GHz:Up to 867Mbps 2.4GHz:Up to 450Mbps *
Wireless Functions	Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power on dBm) QoS(WMM) Band Steering Load Balance MU-MIMO * Airtime Fairness * Beamforming * Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics based on SSID/AP/Client
Wireless Security	Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID to VLAN Mapping Rogue AP Detection 802.1X Support
Transmission Power	CE: ≤20dBm(2.4GHz,EIRP) ≤23dBm(5GHz,EIRP) FCC: ≤24dBm(2.4GHz) ≤22dBm(5GHz)

MANAGEMENT
Omada App	Yes
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Cloud Access	Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
EAP Controller Software	Yes
Email Alerts	Yes
LED ON/OFF Control	Yes
Management MAC Access Control	Yes
SNMP	v1,v2c
System Logging Local/Remote Syslog	Local/Remote Syslog
Telnet	Yes
SSH	Yes
Web-based Management	HTTP/HTTPS
L3 Management	Yes
Multi-site Management	Yes
Management VLAN	Yes

OTHERS
Certification	CE, FCC, RoHS
Package Contents	AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225 Passive PoE Adapter Power Cord Mounting Kits Installation Guide
System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Environment	Operating Temperature: 0℃~60℃ (32℉~144℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Warranty	Limited 5-Year Warranty For further information on our warranty policy please visit: http://www.tp-link.com.au/support/rma

TP-Link EAP225 |AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point Fast Dual-Band Wi-Fi: ‚  Simultaneous 450 Mbps on 2.4 GHz ‚  and 867 Mbps on 5 GHz totals 1317 Mbps Wi-Fi speeds. ‚   Integrated into Omada SDN: Zero-Touch Provisioning (ZTP) ‚ , Centralised Cloud Management, and Intelligent Monitoring. Centralised Management: Cloud access and Omada app for ultra convenience and easy management. Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations. ‚ § PoE ‚  Support: Support both ‚  standard 802.3af/at and Passive PoE (PoE adapter included) ‚  for flexible installations. Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies. Advanced Wireless Tech: Optimize network performance with MU-MIMO, Band Steering, Airtime Fairness and Beamforming technologies. What is Omada Cloud SDN? ‚   ‚   ‚   Omada Installation and Configuration Guide ‚  Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition. ‚ Zero-Touch Provisioning requires the use of Omada Cloud-Based Controller. ‚ §Seamless Roaming requires that clients need to support 802.11k/v and may require additional set up. Performance may vary depending on the client device. The functions of MU-MIMO, Airtime Fairness and ‚  Beamforming, specifications ‚  of ‚  3 Internal Omni ‚  antenna, 450 Mbps on 2.4 GHz and Passive PoE are only supported by EAP225 v3. ‚   ‚   ‚   WHY 4CABLING? 100% Aussie owned and operated. Expert advice and sales team. Trusted by over 100,000 Aussie customers ISO 9001, NSW & QLD government approved supplier Massive stock levels, ready to go Lightning fast delivery nationwide Warranty & easy return policy Secure online shopping 24/7
