Experience blazing-fast, next-generation wireless networking with the TP-Link EAP653 UR AX3000 Access Point. Engineered for demanding business environments, this device delivers ultra-fast WiFi 6 speeds, reaching up to 2402Mbps on the 5GHz band and 574Mbps on the 2.4GHz band. Its ultra-range capabilities, powered by high-gain internal antennas and advanced transmit power, ensure extensive and reliable coverage throughout your premises, eliminating dead zones and providing a seamless connection for all users.

The EAP653 UR is designed for high-density environments, effortlessly supporting over 250 concurrent clients with greater efficiency thanks to OFDMA and MU-MIMO technologies. It leverages the 160MHz channel to double data throughput at peak times, making it perfect for bandwidth-intensive tasks like video conferencing and 4K streaming. The sleek, ultra-slim design allows for discreet ceiling or wall mounting, blending seamlessly into any professional setting while offering maximum agility in deployment.

Seamlessly integrate the EAP653 UR into the Omada Software Defined Networking (SDN) platform for 100% centralised cloud management. This allows you to control your entire network from a single interface. Features like Omada Mesh and Seamless Roaming (802.11k/v/r) ensure uninterrupted connectivity, while flexible power options support both 802.3at PoE+ and 12V DC. Please note that a PoE injector and DC adapter are sold separately.

FEATURES

• AX3000 WiFi 6 Speeds: Delivers combined speeds up to 2976Mbps (2402Mbps on 5GHz and 574Mbps on 2.4GHz).
• Ultra-Range Coverage: High-power antennas provide robust and extensive wireless coverage.
• High-Efficiency WiFi 6: Supports OFDMA, MU-MIMO, and HE160 (160MHz bandwidth) for faster speeds and more connected devices.
• Centralised Cloud Management: Fully integrates with the Omada SDN platform for control from anywhere, anytime.
• Seamless Roaming: 802.11k/v/r support ensures uninterrupted streaming and voice calls as users move.
• Omada Mesh: Enables wireless connectivity between access points for extended range and flexible deployment.
• Flexible Power Options: Supports both 802.3at PoE+ and 12V DC power for installation (PoE injector and DC adapter sold separately).
• Ultra-Slim Design: Elegant and compact (160mm x 33.6mm) for discreet ceiling or wall mounting.

SPECIFICATIONS

• Interface: 1x Gigabit Ethernet (RJ-45) Port (supports IEEE802.3at PoE)
• Power Supply: 802.3at PoE or 12V/1.5A DC (PoE Injector and DC Adapter Not Included)
• Power Consumption: 14.2W (EU) / 15.5W (US)
• Dimensions (W x D x H): 160 x 160 x 33.6mm
• Antenna Type: Internal Omni
  • 2.4GHz: 2x 5dBi
  • 5GHz: 3x 5dBi
• Wireless Standards: IEEE 802.11ax/ac/n/g/b/a
• Frequency: 2.4GHz and 5GHz
• Signal Rate:
  • 5GHz: Up to 2402Mbps
  • 2.4GHz: Up to 574Mbps
• Wireless Security: WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, Captive Portal Authentication, 802.1X Support
• Management: Omada App, Centralised Management (Omada Hardware/Software/Cloud-Based Controller)
• Mounting: Ceiling/Wall mounting (kits included), Junction Box mounting
• Certifications: CE, FCC, RoHS

WARRANTY

5-Year Limited Warranty
