The TP-Link EAP650 D30-Outdoor is a high-performance Omada AX3000 Wi-Fi 6 access point designed to deliver precision connectivity in demanding environments. Featuring built-in 30° high-gain directional antennas, it provides an ultra-range focused signal, making it the premier choice for long-range outdoor bridges or providing dedicated wireless coverage to specific areas in large warehouses.

Engineered for resilience, this unit boasts an IP68 waterproof and dustproof enclosure capable of withstanding extreme Australian conditions, from blistering 70°C heat to -30°C cold. The robust hardware ensures reliable operation in exposed outdoor scenes or harsh industrial settings where standard equipment would fail.

Equipped with advanced Wi-Fi 6 technology, the EAP650 D30-Outdoor delivers combined speeds of up to 2402Mbps on the 5GHz band and 574Mbps on the 2.4GHz band. It supports seamless roaming (802.11k/v/r), ensuring that mobile assets like AGVs and handheld scanners maintain uninterrupted connections as they move throughout a facility.

Integration is simplified through Omada Mesh and PoE+ support, allowing for flexible deployment without extensive data cabling. Managed via the Omada Centralised Cloud platform, administrators can monitor and configure the entire network from a single interface, ensuring professional-grade control and zero-touch provisioning.

FEATURES
High-speed Wi-Fi 6 with up to 2402Mbps on 5GHz and 574Mbps on 2.4GHz
Built-in 30° high-gain directional antennas for targeted long-range coverage
IP68-rated weatherproof enclosure for extreme outdoor durability
Seamless Roaming (802.11k/v/r) for uninterrupted mobile connectivity
Supports 802.3at PoE and 48V Passive PoE for flexible installation
Omada Mesh technology for wireless expansion between access points
Centralised Cloud Management via Omada app or Web UI
Wide operating temperature range from -30°C to +70°C
SPECIFICATIONS
Interface: 1× Gigabit Ethernet Port (Supports 802.3at PoE or 48V Passive PoE)
Wireless Standards: IEEE 802.11a/b/g/n/ac/ax
Signal Rate: 5GHz: Up to 2402Mbps; 2.4GHz: Up to 574Mbps
Antenna Type: Built-in Directional (2.4GHz: 2×12dBi; 5GHz: 2×15dBi)
Antenna Beamwidth: 30° Horizontal; 30° Vertical
Max Power Consumption: 14.7W (US); 12.5W (EU)
Enclosure Rating: IP68
Mounting: Wall, Pole, or Ceiling Mount
Wireless Functions: 1024-QAM, OFDMA, MU-MIMO, Band Steering, Beamforming
Wireless Security: WPA3-Personal/Enterprise, Captive Portal, 802.1X
Dimensions: 207.5×58×230mm
Bluetooth: Yes (for management)
Concurrent Clients: 250+
WARRANTY

1-Year Limited Warranty
