Thor | RF11iQP | 1RU 11 Way Smart Guard Remote Power Rail

The Smart Rack Guard iQ (RF11iQP) has been designed with industry-leading technology of integration of secure IP based monitoring functions with the ability to communicate via a web browser or smartphone apps. This will allow users, particularly service technicians, immediate advice of any high voltage incident or damage affecting the premium-filtered protector. Control systems can customise RF11iQP functions and features by adding supplied API to become part of the integrated solution.

The RF11iQP has two isolated circuits. One circuit set contains 7 individually controlled Australian pin outlets while the other circuit set contains a single control for 4 IEC outlets giving a combined 11 outlet configuration, of which 8 are remotely controllable. Each circuit has spike and surge protection as well as filtered technology to ensure safe and clean power is supplied to any connected devices.

When it comes to your valuable AV or networking equipment you want the best protection possible.

PROTECTS AV RACK EQUIPMENT; SERVERS; SWITCHES, MODEM, ROUTERS; IP TV; TV DECODERS.

FEATURES
1RU Rack Mountable
Adjustable Side Brackets
Dual Filtered, Isolated and Protected Circuits
7 outlets at the front and 4 x IEC Outlets, at rear
Noise Reduction Filter EMI/RFI (SmartBrain Passive)
Designed and Engineered in Australia
LED Warning if surge protection is compromised
Remotely turn 8 outlets on/off
Automatic reboot for Outlet 1
SPECIFICATIONS
Dimensions: 500mm x 52mm x 210mm
Supply Voltage: 240/Vac 50/Hz
Maximum Current Rating: 10amps/2400 W (Va)
Clamping Voltage: 275Vac
Reaction Time: <1 Nanosecond
Maximum Transient Spike Impulse Current: 156,000 Amps. Equivalent to 39,000 Amps using UL1449 standard
Maximum Energy Dissipation: 3420 Joules. Equivalent to 1140 Joules using UL1449 standard
Noise Reduction Filter: EMI/RFI (SmartBrain Passive)
Total Number of Protected AC Outlets: 11
Earth Leakage Range: Less than 1 miili amp
Operating Conditions: Indoor/AC Mains
Operating Temperatures: -10C/+60C
Cable Length: 2.0 Metres
Network Connection: RJ45 network data port
WARRANTY

6-years limited warranty
