Startech 1-port Gigabit Midspan - Poe+ Injector - 802.3at And 802.3af Poeinj1gw
Features
- Easily connect, power, and operate a Gigabit PoE-powered device (PD)
- Supplies up to 30-watts power output
- Flexible setup, with a desktop-sized, or surface-mountable housing
- Save money by using your existing Cat5 or better Ethernet cable
- Fast, plug-and-play setup and operation, with no configuration required
- Provides one PoE+ (PSE, power and data) 10/100/1000Mbps compliant RJ45 port - 802.3at and 802.3af
- Integrates shielded RJ45 connectors
- Automatically detects the powered device to provide the appropriate level of power output
The PoE midspan is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.
Convenience and cost savings
This versatile PoE injector lets you connect a PoE-powered device (PD) to a non-PoE network switch, so you can avoid the expense and aggravation of replacing your existing switch with a PoE-enabled model. It supplies up to 30 watts of power, so you can easily power and access a high-power PoE-compliant device, such as an IP camera or a wireless access point (WAP), using traditional copper (RJ45) Ethernet cable. The midspan injector makes it easy to extend data and power connectivity to your PoE+ device across long distances, even in a remote location where a typical power outlet isn’t available.
Easy to set up in mixed environments
You can integrate this compact injector discreetly into a variety of environments. It features a surface-mountable housing that’s perfect for installing on walls or under a desk, but it’s also palm-sized, for use on desktop surfaces.
Plus, with plug-and-play operation, you can enjoy fast and hassle-free setup without disrupting your workflow.
Intelligent power allocation
Not sure which class your PoE device is? The Gigabit PoE+ injector automatically detects the power requirements of your connected PoE PD, and delivers the appropriate level of power without damaging your device.
The POEINJ1GW is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
- Ideal for high-power PoE+ devices requiring Gigabit speeds such as PTZ (Pan, Tilt, Zoom) cameras and Wi-Fi® access points (WAP)
- Enable remote installation of touchscreens, information kiosks, and phones in locations where a power connection isn’t available
- Perfect for small and home offices, as well as SMB applications, including system integrations, and IT administration
Connector(s) | |
Connector Type(s) | RJ-45 Female |
Environmental | |
Humidity | 10~90% RH (Non-Condensing) |
Operating Temperature | 0?C to 45?C (32?F to 113?F) |
Storage Temperature | -20?C to 85?C (-4?F to 185?F) |
Hardware | |
Industry Standards | IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T) |
IEEE 802.3af PoE, IEEE 802.3at PoE+ | |
Ports | 1 |
Indicators | |
LED Indicators | Power |
Packaging Information | |
Shipping (Package) Weight | 1 kg [2.3 lb] |
Performance | |
Maximum Cable Length | 100 m [328 ft] |
Maximum Data Transfer Rate | 2 Gbps (Full-Duplex) |
Power Output | Power Output: 48 V DC, 30 W |
Physical Characteristics | |
Color | Black |
Enclosure Type | Plastic |
Product Height | 25 mm [1 in] |
Product Length | 70 mm [2.8 in] |
Product Weight | 50 g [1.8 oz] |
Product Width | 63 mm [2.5 in] |
Power | |
Center Tip Polarity | Positive |
Input Current | 0.75 A |
Input Voltage | 100 ~ 240 AC |
Output Current | 0. 64 A |
Output Voltage | 56 DC |
Plug Type | M |
Power Consumption (In Watts) | 36 |
Power Source | AC Adapter Included |
Special Notes / Requirements | |
Patents and Licenses | The following patents are licensed for this product. This list might not be all inclusive. ? United States Patent No. 5,406,260 (expired) ? United States Patent No. 6,650,622 ? United States Patent No. 7,457,250 ? United States Patent No. 8,155,012 ? United States Patent No. 8,902,760 ? United States Patent No. 8,942,107 ? United States Patent No. 9,019,838 ? United States Patent No. 9,049,019 ? United States Patent Application No. 14/695,456 ? United States Patent Application No. 14/726,940 |
System and Cable Requirements | If your connected devices do not meet the IEEE 802.3af or IEEE 802.3at PoE standard, then the POEINJ1GW will not inject power to the connected device(s) / Ethernet cable(s) |
What's in the Box | |
Included in Package | Gigabit midspan |
power cords (EU, UK, ANZ) | |
quick-start guide | |
screws | |
universal power adapter |
