STARTECH 10/ 100Mbps USB LPR Print Server PM1115U2
This palm-sized print server makes it easy to share a USB printer with users on your network. It’s the ideal solution for home or small office networks.
Reliable, cost-efficient network printing
Enjoy cost-efficient network printing for multiple users. The USB 10/100 Mbps print server lets you share one USB printer with multiple users on your network, instead of having to buy separate printers for each individual workstation.
Place your shared printer in a convenient location
With web-based management, you can set up and monitor the printer server through a web browser, so you can place your printer at any convenient shared location - there’s no need to put your printer next to your computer. You can send print jobs to another user in your home or office, or even to a printer in another country.
Easy to use and install
Compact and lightweight, the print server is easy to install with its straightforward installation wizards and remote web-based management. You simply use a USB cable to connect the print server to your printer’s USB port, then use an RJ45 networking cable to connect it to the rest of your network.
Supports LPR network printing and Bonjour Print Services
The printer server supports the Line Printer Remote (LPR) protocol which enables Internet printing. It also supports Bonjour Print Services, making it easier to find and configure printers on your network.
The PM1115U2 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
| Performance | |
| Auto MDIX | Yes |
| Full Duplex Support | Yes |
| Jumbo Frame Support | 9K max. |
| Packaging Information | |
| Shipping (Package) Weight | 326 g [11.5 oz] |
| Indicators | |
| LED Indicators | Power |
| Link | |
| Activity | |
| Hardware | |
| Ports | 1 |
| Industry Standards | Compliant with IEEE 802.3 10BASE-T and IEEE 802.3u 100BASE-TX |
| Chipset ID | EST - EST2862B |
| Environmental | |
| Storage Temperature | -10?C to 70?C (14?F to 158?F) |
| Operating Temperature | 0?C to 40?C (32?F to 104?F) |
| Humidity | 10% ~ 90% RH |
| Connector(s) | |
| External Ports | USB Type-A (4 pin) USB 2.0 Female |
| RJ-45 Female | |
| Performance | |
| Max Distance | 100 m / 330 ft |
| Power | |
| Output Current | 1A |
| Output Voltage | 5 DC |
| Plug Type | H |
| Power Consumption (In Watts) | 2 |
| Power Source | AC Adapter Included |
| Software | |
| OS Compatibility | Windows? XP, 7, 8 / RT, 10 Windows Server? 2003, 2008 R2, 2012 Mac OS? 10.6 to 10.10 |
| Special Notes / Requirements | |
| Note | OS Compatibility refers to the included software only - the Print Server itself can be used without software on most platforms that support network printing |
| System and Cable Requirements | Printer with USB connection |
| USB printer cable not included | |
| What's in the Box | |
| Included in Package | quick start guide |
| RJ45 network cable | |
| software CD | |
| universal power adapter (NA/JP, UK, EU, ANZ) | |
| USB 2.0 network LPR print server | |
| Performance | |
| Maximum Data Transfer Rate | 100 Mbps |
| Remote Management Ability | Yes |
| Supported Protocols | LPR |
| Physical Characteristics | |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 23 mm [0.9 in] |
| Product Length | 53 mm [2.1 in] |
| Product Weight | 62 g [2.2 oz] |
| Product Width | 54 mm [2.1 in] |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.25 |
| Input Voltage | 100 ~ 240 AC |
This palm-sized print server makes it easy to share a USB printer with users on your network. It?s the ideal solution for home or small office networks.
Reliable, cost-efficient network printing
Enjoy cost-efficient network printing for multiple users. The USB 10/100 Mbps print server lets you share one USB printer with multiple users on your network, instead of having to buy separate printers for each individual workstation.
Place your shared printer in a convenient location
With web-based management, you can set up and monitor the printer server through a web browser, so you can place your printer at any convenient shared location - there?s no need to put your printer next to your computer. You can send print jobs to another user in your home or office, or even to a printer in another country.
Easy to use and install
Compact and lightweight, the print server is easy to install with its straightforward installation wizards and remote web-based management. You simply use a USB cable to connect the print server to your printer?s USB port, then use an RJ45 networking cable to connect it to the rest of your network.
Supports LPR network printing and Bonjour Print Services
The printer server supports the Line Printer Remote (LPR) protocol which enables Internet printing. It also supports Bonjour Print Services, making it easier to find and configure printers on your network.
The PM1115U2 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
