Startech 2-port Displayport Dual-monitor Kvm Switch - Displayport Kvm - 4k 60 Hz - Access Two Dual-monitor

SKU
253872
Brand
MPN
SV231DPDDUA2
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $640.00 Regular Price $736.00
Buy Now And Earn 640 Reward Points!

QUICK OVERVIEW

computers and two shared USB SV231DPDDUA2

This dual DisplayPort KVM switch combines next-generation digital display standards with seamless KVM control. The 2-port KVM switch features audio and USB peripheral support along with dual-display capability, which makes it easy to create a multimedia workstation that can switch between two dual-head or twin DisplayPort systems.

Maximize productivity with dual video

With support for two DisplayPort video inputs and two different computers, this KVM switch helps maximize productivity.You can access multiple computers, giving you the freedom to multitask and increase your productivity. Each of the DP ports supports resolutions up to 4K for maximum screen viewing space.

You can also use low-cost adapters to achieve a dual-monitor setup using your computer's secondary HDMI or DVI port.

Astonishing picture quality

The dual DisplayPort KVM switch supports resolutions up to Ultra HD 4K at 60Hz, and can drive two large DP displays with ease. This makes it the ideal solution for creating workstations where high-quality imaging is critical, such as for graphic design.

Complete multimedia control

The KVM switch features auxiliary 3.5 mm audio ports that let you share independent analog audio, from each of your connected computers, with your desktop speaker set. With independent audio support, along with dual 4K DP video, you get full multimedia control between different computers which makes this the perfect KVM switch for creative professional applications such as video and sound design or editing.

Convenient peripheral sharing

This KVM switch offers a built-in 2-port USB hub that's separate from your HID keyboard and mouse. This enables you to share USB peripherals between each connected computer and avoid the expense of separate equipment. The USB hub automatically switches your connected USB devices to the selected computer, saving you the hassle and cost of outfitting each of your computers with their own peripherals.

The SV231DPDDUA2 is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Connector(s)
Console Interface(s)3.5 mm Mini-Jack (3 Position) Female
DisplayPort (20 pin) Female
USB Type-A (4 pin) USB 2.0 Female
Host Connectors3.5 mm Mini-Jack (3 Position) Female
DisplayPort (20 pin) Female
USB B (4 pin) Female
Environmental
Humidity0~80% RH
Operating Temperature0?C to 40?C (32?F to 104?F)
Storage Temperature20?C to 60?C (-4?F to 140?F)
Hardware
AudioYes
Cables IncludedNo
Daisy-ChainNo
KVM Ports2
Number of Monitors Supported2
PC InterfaceUSB
PC Video TypeDisplayPort
Rack-MountableNo
Indicators
LED Indicatorscomputer LEDs
Packaging Information
Shipping (Package) Weight0.2 kg [0.3 lb]
Performance
Aspect RatioWide (16:9)
DVI SupportNo
Hot-Key SelectionYes
IP ControlNo
Maximum Digital Resolutions3840 x 2160 (Ultra HD 4K) @ 60hz
Maximum Number of Users1
On-Screen DisplayNo
Port Selection SupportPush Button and Hotkeys
Supported Resolutions1024x768
1280x720 (High-definition 720p)
1920x1080 (High-definition 1080p)
1920x1200
2560x1600
3840 x 2160 (4K)@ 60hz
Wide Screen SupportedYes
Physical Characteristics
ColorBlack
Enclosure TypeSteel
Product Depth100 mm [3.9 in]
Product Height57.5 mm [2.3 in]
Product Weight734 g [25.9 oz]
Product Width161 mm [6.3 in]
Power
Center Tip PolarityPositive
Input Current0.6 A
Input Voltage100 ~ 240 AC
Output Current1.5 A
Output Voltage12 DC
Power SourceAC Adapter Included
What's in the Box
Included in Packageinstruction manual
KVM switch
rubber feet
universal power adapter (NA/JP, EU, UK, ANZ)
