Dell Pro Smart Dock - SD25 - 130W Power Delivery - 2 x DP, 1 x HDMI, 2 x USB-C, 4 x USB-A - 2.5GbE RJ-45 - 3 Year Warranty 210-BRJV
A smarter workspace
Gain the versatility to create your ideal workspace and boost your AI PC productivity with support for up to 4 displays, up to 130W power delivery, and multiple ports to connect all your peripherals.
Remotely manageable
Elevate the IT management experience with no software or PC connection required, allowing you to remotely manage all your Dell Pro Smart Docks.
Remotely manageable
Remotely manage your smart docks without end-user presence from the Dell Device Management Console - a holistic peripheral management solution that configures, deploys, and updates smart docks over Wi-Fi.
Work securely
Keep users working confidently with enterprise-grade WPA-3 192-bit encryption for secure Wi-Fi communication. Safeguard your sensitive data with tamper-resistant, hardware-based encryption built into your Dell Pro Smart Dock.
Effortless maintenance
Reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions.
Connect your way
Configure your workspace to your liking with an ambidextrous USB-C cable[1] that can be routed left or right.
Designed for sustainability
The Dell Pro Smart Dock is built with post-consumer recycled materials and packaged with recycled or renewable packaging.
| Network & Communication | |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information |
|
| Power Description | |
| Maximum Power Supply Wattage | 180 W |
| Power Source Type | Power Adapter |
| Miscellaneous | |
| Package Contents |
|
| Post-consumer-waste% | 65% |
| Kensington Security Slot | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 562 g |
| Height | 205 mm |
| Width | 90 mm |
| Depth | 35.3 mm |
| Software | |
| Operating System Supported | Ubuntu 24.04 |
| Windows 11 | |
| Windows 10 | |
| Red Hat Enterprise Linux 9.6 | |
| ChromeOS | |
| General Information | |
| Product Type | Docking Station |
| Manufacturer Part Number | 210-BRJV |
| Manufacturer Website Address | http://www.dell.com.au |
| Manufacturer | Dell Technologies |
| Product Model | SD25 |
| Product Name | Pro Smart Dock - SD25 |
| Brand Name | Dell |
| Interfaces/Ports | |
| Host Interface | USB Type C |
| HDMI | Yes |
| HDMI Version | 2.1 |
| Number of HDMI Ports | 1 |
| Network (RJ-45) | Yes |
| DisplayPort | Yes |
| Total Number of USB Ports | 6 |
| Number of DisplayPorts | 2 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x USB-C 3.2 Gen 2 (15W), 1 x USB-C Multi-function DisplayPort (7.5W) |
| DisplayPort Version | 1.4 |
| Number of USB Type-C Ports | 2 |
| Number of USB Type-A Ports | 4 |
| Number of USB 3.2 Gen 2 Type-A Ports | 4 |
| USB Type-A | Yes |
| Technical Information | |
| Cable Length | 90 cm |
| Device Supported | Desktop PC |
| Notebook | |
| Connectivity Technology | Wired |
| Features | Power Delivery Pass-through |
| Maximum Data Transfer Rate | 1.25 GB/s |
| Number of Displays Supported | 4 |
| Supported Resolutions | 3440 x 1440 |
| 3840 x 2160 | |
| 1280 x 720 | |
| 5120 x 2160 | |
| 1920 x 1080 | |
| 6144 x 3456 | |
| 2560 x 1440 | |
| Screen Mode Supported | 6K @ 60Hz |
| FHD @ 60Hz | |
| HD | |
| 5K @ 60Hz | |
| 4K @ 60Hz | |
| WQHD @ 60Hz | |
| QHD @ 60Hz | |
| Management Features | Wake-on-LAN |
| PXE Boot | |
| Dock Power Button Sync | |
| Port Disablement | |
| WLAN to LAN Switch | |
| Kernel Direct Memory Access (DMA) Protection | |
| MAC Address Pass-through | |
| Power Delivery | 96W (non-Dell Systems) |
| 130W (Dell Systems) | |
| Video Resolution Details | WQHD - 60 Hz (Triple Display) |
| WQHD - 60 Hz (Quad Display) | |
| QHD - 60 Hz (Dual Display) | |
| HD - 60 Hz (Quad Display) | |
| FHD - 60 Hz (Triple Display) | |
| 6K - 60 Hz (Single Display) | |
| 4K - 60 Hz (Single Display) | |
| 5K - 60 Hz (Dual Display) | |
| Security Slot Type | Kensington Security Slot |
| Power Delivery Details |
|
