4Cabling's Premium Server Racks have been designed as a high-quality cable management solution, ideal for data centres and equipment rooms. These server cabinets are designed to be easily installed and are reinforced using heavy-duty mounting rails and castor wheels.

This premium server rack comes supplied fully assembled complete with front & rear bi-fold mesh doors and split side panels. The split rear doors greatly improve access to the server rack as only limited clearance is needed to open the door - making it perfect for data centres or space-limited environments. The racks 2 point locking systems ensure the security of the cabinet and the stability of the door.

Cable access is achievable via the roof or base by removable gland plates. 4Cabling premium server cabinets are built around universal 19" standards, to deliver compatibility with both leading vendor equipment manufacturers as well as OEM brands. A wide range of 19" server rack accessories are available from 4Cabling to complement the server rack.

FEATURES
Supplied fully assembled for rapid deployment
Lockable bi-fold mesh front and rear doors for enhanced security and space efficiency
Heavy-duty construction with SPCC cold-rolled steel and 2mm thick rails and frame
Integrated cable management rails at the front and rear
Includes a 4-way ceiling mount fan kit and a 10-way vertical mounted power rail
Comes with 40 sets of cage nuts, 2 fixed shelves, and 1 sliding shelf
Adjustable 19" L rails with RU markings for easy equipment mounting
Features levelling feet and lockable castor wheels for stability and mobility
Multiple cable entry glands on the top and bottom for versatile cable routing
Earthed doors and side panels for added safety
SPECIFICATIONS
Rack Unit Size: 45RU
Width: 800mm
Depth: 1070mm
Height: 2130mm
Internal Width: 470mm
Internal Depth (Front Rail to Back Door): 880mm
Rail to Rail Depth: 590mm
Static Loading Capacity: 1500kg
Material: SPCC Cold-Rolled Steel
Steel Thickness: Rails and Frame 2mm, Front Door 1.5mm, Rear Door, Shelves, and Cable Management 1.2mm
Surface Finish: Powder Coated, Black Sand Grain
Fans: 4 x Roof Mount
Power Distribution Unit (PDU): 1 x 10 Way Vertical
Shelves: 2 x Fixed (440mm width x 550mm depth), 1 x Sliding (420mm width x 500mm depth)
Cable Entry Glands: 4 x 350mm(w) x 50mm(d) on the bottom, top glands not specified
Castor Height: 40mm
Weight: 165kg
Standards: Designed/built to ANSI EIA/ECA-310-E, IEC 297-2, DIN 41491/41494
WARRANTY

3-Years Limited Warranty
