6C-WIEGAND GARLAND WORK GREY SEC CABLES 300M PULL BOX MC76S300BW
SKU
409396
Brand
MPN
6C-WIEGAND-PB-300-GREY
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$234.00
Buy Now And Earn 234 Reward Points!
The Garland Work 6C-7020 screened Wiegand cable is designed for low-bit-rate serial data applications and includes a screen to protect against electrical interference. Ideally suited for short-run applications to connect motion and entry sensors (reed switches) or card readers and door strikes. Available in 100m spools and 300m pull box.
| Cores | 6 |
| Conductor AWG | 24 |
| Conductor Stranding (mm) | 7/020 |
| Material | Tinned Annealed Copper Wire |
| Applicable Standards | AS/ACIF S008, AS 1049, UL444 |
| ROHS Compliant | Yes |
| A-Tick | Yes |
| Insulation Material | Polypropylene |
| Outer Sheath Material | 4V-75 PVC |
| Shielding | Aluminium Polyester Tape Overall Screen |
| Colour | Grey |
6C-WIEGAND GARLAND WORK GREY SEC CABLES 300M PULL BOX
